Introduction: 2.1 mJ / 228.5 fs / 0.26% RMS@24h — One Laser, Two THz Routes

The terahertz band (0.1 – 10 THz) penetrates paper, plastics, and ceramics non-destructively, yet is strongly absorbed by water and reflected by metals. This selective transparency makes THz invaluable for security imaging, non-destructive testing, pharmaceutical QC, semiconductor metrology, and 6G communications. But efficient THz generation invariably requires a femtosecond laser driver.

WAVEQUANTA recently delivered a HELIOS-20W-HE high-energy femtosecond front-end + AURORA-IR-HE mid-IR OPA system to a leading research university. The HELIOS measures 2.1 mJ / 228.5 fs / 21.42 W at 10 kHz, with 24-hour power stability of 0.26% RMS and M² < 1.13 — directly satisfying the pump requirements for both LiNbO₃ optical rectification and mid-IR DFG-based THz generation. The AURORA-IR-HE covers 1360 – 4500 nm continuous tuning at 15.86% peak conversion efficiency (@ 1650 nm).

1. Two Mainstream THz Generation Routes

1.1 LiNbO₃ (LN) Optical Rectification

A femtosecond pulse is focused into MgO:LiNbO₃; optical rectification converts the pulse envelope into a THz electric-field transient. A tilted-pulse-front scheme provides velocity matching, yielding > 10 µJ single-pulse THz energy — among the strongest table-top THz sources. Requirements: pump wavelength 1000 – 1064 nm, pulse energy 0.5 – 2 mJ, pulse duration 200 – 500 fs (shorter pulses trigger crystal damage), and high beam quality for uniform pulse-front tilt.

1.2 GaP / ZnTe Difference-Frequency Generation

Near-IR or mid-IR femtosecond pulses enter GaP or ZnTe crystals, producing broadband THz via nonlinear DFG. GaP covers > 7 THz bandwidth, ideal for THz-TDS. Mid-IR OPA output (2 – 4.5 µm) as the DFG source generates higher-frequency THz and avoids the phonon absorption limitation of the LN route.

2. Hard Specifications for the THz Driver

Right column: factory-measured values from this delivery — all five specifications met.

3. HELIOS-20W-HE: Factory-Measured Data

The HELIOS-20W-HE uses all-solid-state Yb CPA architecture, directly diode-pumped (~9% quantum defect). Measured parameters across three repetition rates:

▪ 10 kHz: 228.5 fs / 2.1 mJ / 21.42 W

▪ 50 kHz: 246.3 fs / 428 µJ / 21.42 W

▪ 100 kHz: 249.1 fs / 214 µJ / 21.42 W

Stability metrics (24-hour continuous burn-in):

▪ Power stability: RMS = 0.26%

▪ Pointing stability: 8.7 µrad

▪ Beam quality: M²x = 1.127 / M²y = 1.128 @ 10 kHz

The 228.5 fs pulse duration sits in the sweet spot for LN optical rectification: short enough for efficient nonlinear conversion, long enough to avoid LiNbO₃ damage threshold. The 0.26% RMS stability over 24 hours means pump noise contribution to THz-TDS signals is negligible during extended scans.

HELIOS-20W-HE autocorrelation: 228.5 fs FWHM @ 10 kHz / 2.1 mJ

HELIOS-20W-HE 24h power stability: RMS = 0.26% @ 10 kHz / 21.42 W

HELIOS-20W-HE 24h pointing stability: 8.7 µrad @ 10 kHz

4. AURORA-IR-HE: Mid-IR OPA — The Second THz Route

The AURORA-IR-HE takes 1.4 mJ / 14 W (after beam splitting) from the HELIOS as pump, converting wavelength from 1036.8 nm to 1360 – 4500 nm via optical parametric amplification (OPA). Its mid-IR output drives GaP/GaSe DFG for broadband THz and also serves molecular vibrational spectroscopy (pump-probe, 2D-IR).

Key measured data:

▪ Tuning range: 1360 – 4500 nm (signal + idler full coverage)

▪ Peak conversion efficiency: 15.86% @ 1650 nm (2220 mW output), spec > 9%

▪ Second peak: 11.48% @ 2044.74 nm (1607 mW)

▪ Power stability: RMS = 0.39% @ 1550 nm / 15 h continuous

▪ Pump injection: 1.4 mJ / 14 W @ 10 kHz

AURORA-IR-HE signal + idler power tuning curve: 1360 – 4500 nm full coverage

AURORA-IR-HE 15h power stability: RMS = 0.39% @ 1550 nm

5. One Platform, Two THz Routes

The HELIOS-20W-HE + AURORA-IR-HE combination delivers:

▪ Route A (LN optical rectification): HELIOS main output 2.1 mJ / 228.5 fs pumps MgO:LiNbO₃ via tilted-pulse-front for > 10 µJ single-pulse THz.

▪ Route B (mid-IR DFG): HELIOS split-off 1.4 mJ pumps AURORA-IR-HE; OPA output at 2 – 4.5 µm enters GaP/GaSe for broadband THz with wider frequency coverage and no phonon absorption limit.

One femtosecond platform supports two complementary THz schemes — one optimized for single-pulse energy, the other for frequency coverage. 24-hour 0.26% RMS stability ensures long-run experimental consistency on both routes.

6. Summary

2.1 mJ, 228.5 fs, 0.26% RMS @ 24h — three numbers from the HELIOS-20W-HE that map directly to THz generation's energy threshold, pulse-duration sweet spot, and long-term stability requirement. Paired with the AURORA-IR-HE's 1360 – 4500 nm tuning, one platform covers both LN optical rectification and mid-IR DFG THz routes.
