16 mm coaxial mounting plate — Model CP16-5
✔ In Stock — Ships Today
LBTEK 16 mm Coaxial Mounting Plate CP16-XX features dual retaining rings for securing optical components, compatible with optical elements ranging from Ø5 mm to Ø12 mm in diameter, designed with a compact structure. It includes four coaxial through-holes for mounting Ø4 mm posts, secured by side M4 set screws adjustable with a 2.0 mm hex wrench. Both sides are equipped with M4 threaded holes for direct attachment to posts. Additionally, it can be mounted onto 16 mm coaxial cubes using four M2.5 pan head screws.
Key Features
- Double snap rings for securing optical components, compatible with optical component diameters: Ø5 mm~Ø12 mm
- Comes with 4 coaxial through holes for mounting Ø4 mm rods
- Side M4 threaded holes for secure attachment to rods
- Mounts to 16 mm coaxial cubes using M2.5 pan head screws
Application
Application Installation Diagram
| Clear Aperture | 3.8 mm |
CAD Drawing
Download
Click and drag to rotate. Scroll to zoom.
Product Family: 16 mm coaxial mounting plate (10 variants)
| Product | SKU | Size | Clear Aperture | Operating Wavelength | |
|---|---|---|---|---|---|
| 16 mm coaxial mounting plate CP16-12 |
CP16-12
| — | — | — | View |
| 16 mm coaxial mounting plate CP16-11 |
CP16-11
| — | — | — | View |
| 16 mm coaxial mounting plate CP16-10 |
CP16-10
| — | — | — | View |
| 16 mm coaxial mounting plate CP16-9 |
CP16-9
| — | — | — | View |
| 16 mm coaxial mounting plate CP16-8 |
CP16-8
| — | — | — | View |
| 16 mm coaxial mounting plate CP16-7 |
CP16-7
| — | — | — | View |
| 16 mm coaxial mounting plate CP16-6 |
CP16-6
| — | — | — | View |
| 16 mm coaxial mounting plate CP16-5 Current |
CP16-5
| — | — | — | |
| 16 mm coaxial mounting plate CP16-16 |
CP16-16
| — | — | — | View |
| 16 mm coaxial mounting plate CP1605 |
CP1605
| — | — | — | View |
