Metal Film Flat Mirrors, UV-enhanced Aluminum Coating: 250 nm-600 nm, circular PM05-UVAL-SP

Metal Film Flat Mirrors, UV-enhanced Aluminum Coating: 250 nm-600 nm, circular — Model PM05-UVAL-SP

Operating wavelength 250 nm-600 nm, Ø12.7 mm, substrate UVFS.

Product Description

• Optical Material: Borofloat Glass, UVFS
• Silicon Dioxide Protective Layer
• Working Wavelength: 250 nm-600 nm, 250 nm-450 nm
• Application: Optical Path Deflection, Beam Splitting

UV-enhanced aluminum-coated mirrors are highly suitable for beam deflection (O-shaped, elliptical) and beam splitting (D-shaped) across a broad ultraviolet spectrum, offering high reflectivity over a wide spectral range. The reflection of the beam occurs on the metal film surface, eliminating chromatic aberration. However, metal films are prone to oxidation, discoloration, or peeling in high-humidity environments. LBTEK's UV-enhanced aluminum-coated mirrors feature a protective silicon dioxide layer on the surface to isolate the metal film from direct contact with air, preventing oxidation and preserving optical performance. LBTEK offers UV-enhanced aluminum-coated mirrors in various shapes, including circular, elliptical, and D-shaped, among others. All our mirrors undergo precision machining and strict quality control to ensure that LBTEK provides high-quality mirror products at reasonable prices. For customized metal-coated mirrors, please contact LBTEK Technical Support.

Metal Film Flat Mirrors, UV-enhanced Aluminum Coating: 250 nm-600 nm, circular

• Substrate Material: Borofloat Glass, UVFS
• Silicon Dioxide Protective Layer
• Operating Wavelength: 250 nm-600 nm
• Application: Optical Path Deflection

LBTEK offers UV-enhanced aluminum-coated flat mirrors, which are highly suitable for beam deflection in the ultraviolet spectral range, featuring high reflectivity across a broad spectrum. The reflection of the beam on the metal-coated surface does not introduce chromatic aberration. Metal coatings are prone to oxidation, discoloration, or peeling in high-humidity environments. LBTEK's metal-coated mirrors are coated with a layer of silicon dioxide protective film on the surface to isolate the metal coating from direct contact with air, preventing oxidation and preserving optical performance.
