Metal Film Flat Mirrors, UV-enhanced Aluminum Coating: 250 nm-600 nm, elliptical PM10E-UVAL

Metal Film Flat Mirrors, UV-enhanced Aluminum Coating: 250 nm-600 nm, elliptical — Model PM10E-UVAL

Operating wavelength 250 nm-600 nm, substrate UV Fused Silica.

Product Description

• Optical Material: Borofloat Glass, UVFS
• Silicon Dioxide Protective Layer
• Working Wavelength: 250 nm-600 nm, 250 nm-450 nm
• Application: Optical Path Deflection, Beam Splitting

UV-enhanced aluminum-coated mirrors are highly suitable for beam deflection (O-shaped, elliptical) and beam splitting (D-shaped) across a broad ultraviolet spectrum, offering high reflectivity over a wide spectral range. The reflection of the beam occurs on the metal film surface, eliminating chromatic aberration. However, metal films are prone to oxidation, discoloration, or peeling in high-humidity environments. LBTEK's UV-enhanced aluminum-coated mirrors feature a protective silicon dioxide layer on the surface to isolate the metal film from direct contact with air, preventing oxidation and preserving optical performance. LBTEK offers UV-enhanced aluminum-coated mirrors in various shapes, including circular, elliptical, and D-shaped, among others. All our mirrors undergo precision machining and strict quality control to ensure that LBTEK provides high-quality mirror products at reasonable prices. For customized metal-coated mirrors, please contact LBTEK Technical Support.

Metal Film Flat Mirrors, UV-enhanced Aluminum Coating: 250 nm-600 nm, elliptical

• Substrate Material: UVFS
• Silicon Dioxide Protective Coating
• Operating Wavelength: 250 nm-600 nm
• Dimensions: Elliptical, Minor Axis 12.7 mm or Minor Axis 25.4 mm

LBTEK offers elliptical ultraviolet-enhanced aluminum-coated metal plane mirrors with short axes of 12.7 mm or 25.4 mm. Metal-coated mirrors are highly suitable for deflecting broadband light sources, as they provide high reflectivity across a wide spectral range. Metal coatings are prone to oxidation, discoloration, or peeling in high-humidity environments. To prevent direct contact between the metal coating and air, LBTEK's metal-coated mirrors are coated with a protective layer of silicon dioxide on the surface.
