65 Stage XYZ-axis 9 mm Linear Piezo Actuator Stage, Right-Driven LS65-9R3-P
LS65-9R3-P$4,351.14
In Stock
Design Tools
Photonics Calculators
Explore 49 free online calculators for photonics design
Unit Converters
Convert between wavelength, frequency, power, and more
View all 49 calculators →
RoHS
REACH
LBTek 65-Stage 9 mm Linear Piezoelectric Actuator Stage — XYZ 3-Axis, Right-Driven Configuration.
| Number of axes | XYZ (3-axis) |
| Drive position | Right-driven |
| Travel | 9 mm × 9 mm × 9 mm |
| Tabletop size | 65 mm × 65 mm |
| Drive type | Piezoelectric screw actuator |
| Typical step size | 10–30 nm |
| Tabletop threaded holes | M6 |
| Material | 6061-T6 aluminum alloy |
| Surface treatment | Black anodized after grinding |
No documents available for this product.
No CAD drawings available for this product.
