95 mm Plan Apochromat Objectives, 400-700 nm PLNAPO20XSL

Name: 95 mm Plan Apochromat Objectives, 400-700 nm PLNAPO20XSL
Brand: LBTek
SKU: PLNAPO20XSL
Price: 2523.30 SGD
Availability: InStock

PLNAPO20XSL

$2,523.30

In Stock

Request Quote

Design Tools

Gaussian Beam Calculator Model beam propagation through your optical system

View all 49 calculators →

Complete Your Setup

Lasers & Sources Mirrors Lenses Detectors & Measurement

RoHS REACH

LBTEK offers plan apochromat objectives with a range of 400 nm to 700 nm. These infinity-corrected plan apochromat objectives are available in 5X, 10X, 20X, 50X, and 100X magnifications. They also feature an extra-long working distance (13 mm at 100X magnification). Each objective has an external M26 mm × 0.706 mm thread, allowing it to be mounted on internally SM1-threaded mounts using the LBTEK SM1-M26A thread adapter.

Key Features

Large numerical aperture, long working distance
Plan apochromatic design
Excellent imaging performance

Application

Mounting the objective onto the TXY1S using the SM1-M26A thread adapter

Operating Wavelength	400 nm-700 nm
Focal length	10 mm
Magnification	20×
Working distance	30 mm
Numerical Aperture	0.29
Objective Field Number	1.2 mm
Parfocal distance	95 mm
Incident aperture	5.8 mm
Weight	236 g
Resolution	0.9 μm
Lens Mount	1.8''
Aperture	0.72 mm×1.07 mm
Optical Correction	Infinity Corrected
Operating Temperature	+5 ~ +40 °C
Field of View	M26 mm×0.706 mm

No documents available for this product.

No CAD drawings available for this product.

Product Family: Long Working Distance Plan Apochromat Objectives (20 variants)

Product ▴▾	SKU	Size ▴▾	Clear Aperture ▴▾	Operating Wavelength ▴▾
95 mm Plan Apochromat Objectives, 400-700 nm PLNAPO5X	`PLNAPO5X`	—	—	—	View
95 mm Plan Apochromat Objective, 500-1200 nm PLNAPO5XNIR	`PLNAPO5XNIR`	—	—	—	View
95 mm Plan Apochromat Objectives, 400-700 nm PLNAPO50XSL	`PLNAPO50XSL`	—	—	—	View
95 mm Plan Apochromat Objectives, 400-700 nm PLNAPO50X	`PLNAPO50X`	—	—	—	View
95 mm Plan Apochromat Objectives, 400-700 nm PLNAPO20XSL Current	`PLNAPO20XSL`	—	—	—
95 mm Plan Apochromat Objectives, 400-700 nm PLNAPO20X	`PLNAPO20X`	—	—	—	View
95 mm Plan Apochromat Objective, 500-1200 nm PLNAPO10XNIR	`PLNAPO10XNIR`	—	—	—	View
95 mm Plan Apochromat Objectives, 400-700 nm PLNAPO10X	`PLNAPO10X`	—	—	—	View
95 mm Plan Apochromat Objectives, 400-700 nm PLNAPO100XSL	`PLNAPO100XSL`	—	—	—	View
95 mm Plan Apochromat Objectives, 400-700 nm PLNAPO100XHR	`PLNAPO100XHR`	—	—	—	View
Long Working Distance Plan Apochromat Objectives PLNAPO10XNIR	`PLNAPO10XNIR`	—	—	—	View
Long Working Distance Plan Apochromat Objectives PLNAPO5XNIR	`PLNAPO5XNIR`	—	—	—	View
Long Working Distance Plan Apochromat Objectives PLNAPO5X	`PLNAPO5X`	—	—	—	View
Long Working Distance Plan Apochromat Objectives PLNAPO10X	`PLNAPO10X`	—	—	—	View
Long Working Distance Plan Apochromat Objectives PLNAPO20X	`PLNAPO20X`	—	—	—	View
Long Working Distance Plan Apochromat Objectives PLNAPO20XSL	`PLNAPO20XSL`	—	—	—	View
Long Working Distance Plan Apochromat Objectives PLNAPO50X	`PLNAPO50X`	—	—	—	View
Long Working Distance Plan Apochromat Objectives PLNAPO50XSL	`PLNAPO50XSL`	—	—	—	View
Long Working Distance Plan Apochromat Objectives PLNAPO100XSL	`PLNAPO100XSL`	—	—	—	View
Long Working Distance Plan Apochromat Objectives PLNAPO100XHR	`PLNAPO100XHR`	—	—	—	View
