Fixed-type sleeve mounting bracket SM05-FR
SM05-FR$25.65
In Stock
Design Tools
View all 49 calculators →Complete Your Setup
RoHS
REACH
Fixed-type sleeve mounting bracket — Model SM05-FR
✔ In Stock — Ships Today
The LBTEK fixed sleeve mounting bracket is specifically designed for installing and securing SM05/SM1/SM2 series sleeves, fixing lens sleeves onto breadboards or optical platforms. The base of the mounting bracket features M4 threaded mounting holes, allowing support with Ø12.7 mm stainless steel optical posts or other connecting components.
Key Features
- Install and secure SM05/SM1/SM2 series sleeves
- Smooth edges, space-saving
- Bottom M4 threaded hole for optical rod connection
Application
Fixed-type sleeve mounting brackets are commonly used to secure optical filters.
| Thickness | 10.0 mm |
CAD Drawing
Download
Click and drag to rotate. Scroll to zoom.
Product Family: Fixed lens sleeve mounting bracket (3 variants)
| Product | SKU | Size | Clear Aperture | Operating Wavelength | |
|---|---|---|---|---|---|
| Fixed-type sleeve mounting bracket SM05-FR Current |
SM05-FR
| — | — | — | |
| Fixed-type sleeve mounting bracket SM1-FR |
SM1-FR
| — | — | — | View |
| Fixed-type sleeve mounting bracket SM2-FR |
SM2-FR
| — | — | — | View |
