What wavelength range does High-quality bandpass filter, FWHM=50 nm MBP25-460-50 support?

High-quality bandpass filter, FWHM=50 nm MBP25-460-50 operates at a center wavelength of 460.0 nm.

What are the physical dimensions of High-quality bandpass filter, FWHM=50 nm MBP25-460-50?

High-quality bandpass filter, FWHM=50 nm MBP25-460-50 dimensions: Diameter: 25.0 mm. Thickness: 3.5 mm.

What documentation is available for High-quality bandpass filter, FWHM=50 nm MBP25-460-50?

The following documents are available for download on the High-quality bandpass filter, FWHM=50 nm MBP25-460-50 product page: Spec sheet. CAD drawing.Visit the Documents tab for direct download links.

Is High-quality bandpass filter, FWHM=50 nm MBP25-460-50 available for purchase?

Yes, request a quote for pricing and lead time at WaveQuanta.Contact our sales team for current availability and volume pricing.

WaveQuanta

High-quality bandpass filter, FWHM=50 nm MBP25-460-50

Name: High-quality bandpass filter, FWHM=50 nm MBP25-460-50
Brand: WaveQuanta
SKU: MBP25-460-50
Price: 251.02 SGD
Availability: InStock

MBP25-460-50

$251.02

In Stock

Key Specifications

Wavelength 460.0nm

Diameter 25.0mm

Request Quote

Design Tools

Wavelength \u2194 Wavenumber Convert between wavelength, frequency, and energy

View all 49 calculators →

RoHS REACH

High-quality bandpass filter, FWHM=50 nm — Model MBP25-460-50

Ø25 mm, substrate UVFS.

Product Description

Stopband range: ODabs>5, 200 nm-1200 nm
FWHM=10±1.5 nm, 50±2 nm
Center wavelength: 355-1064 nm
Ø12.5 mm, Ø25 mm, with mechanical retaining ring

LBTEK high-quality bandpass filters are constructed using UV-grade fused silica substrates and advanced ion beam-assisted hard coating technology. Through precise thin-film design, these filters ensure complete transmission of optical signals within the center wavelength and bandwidth. Currently, the high-quality bandpass filters offer 24 center wavelengths within the range of 355-1064 nm, two sizes (Ø12.5 mm, Ø25 mm), and two bandwidth options (FWHM=10 nm, 50 nm). These products feature high transmittance (>85%, >90%) and high blocking depth (ODabs >5) within the operating wavelength range of 200-1200 nm. They are widely suitable for various application scenarios such as laser processing monitoring, fluorescence imaging, spectral analysis, and optical inspection, meeting diverse needs in optical experiments and industrial applications. Additionally, LBTEK offers customization services for wavelength, bandwidth, and size. For custom orders, please contact technical support.

High-quality bandpass filter, FWHM=50 nm

FWHM: 50±2 nm
Transmittance: >90%
Stopband Optical Density: ODabs >5
Center Wavelength: 460 nm-800 nm
Stopband Range: 200 nm-1200 nm

LBTEK High-Quality Bandpass Filter Mounted on Coaxial Mounting Plate

Clear Aperture	Ø22 mm
Transmittance	> 90%
Thickness	3.5 mm
Diameter	25 mm
Operating Temperature	-40-+90 °C
Center Wavelength	460 nm-800 nm

Specification Sheet PDF — Download

CAD Drawing Download

3D Model (STL) STL — Download

Product Family: High-quality bandpass filter (48 variants)

Product ▴▾	SKU	Size ▴▾	Clear Aperture ▴▾	Operating Wavelength ▴▾
High-quality bandpass filter, FWHM=50 nm MBP25-800-50	`MBP25-800-50`	25 mm	Ø22 mm	—	View
High-quality bandpass filter, FWHM=50 nm MBP12-800-50	`MBP12-800-50`	12.5 mm	9 mm	—	View
High-quality bandpass filter, FWHM=50 nm MBP25-650-50	`MBP25-650-50`	25 mm	Ø22 mm	—	View
High-quality bandpass filter, FWHM=50 nm MBP12-650-50	`MBP12-650-50`	12.5 mm	9 mm	—	View
High-quality bandpass filter, FWHM=50 nm MBP25-600-50	`MBP25-600-50`	25 mm	Ø22 mm	—	View
High-quality bandpass filter, FWHM=50 nm MBP12-600-50	`MBP12-600-50`	12.5 mm	9 mm	—	View
High-quality bandpass filter, FWHM=50 nm MBP25-550-50	`MBP25-550-50`	25 mm	Ø22 mm	—	View
High-quality bandpass filter, FWHM=50 nm MBP12-550-50	`MBP12-550-50`	12.5 mm	9 mm	—	View
High-quality bandpass filter, FWHM=50 nm MBP25-525-50	`MBP25-525-50`	25 mm	Ø22 mm	—	View
High-quality bandpass filter, FWHM=50 nm MBP12-525-50	`MBP12-525-50`	12.5 mm	9 mm	—	View
High-quality bandpass filter, FWHM=50 nm MBP25-460-50 Current	`MBP25-460-50`	25 mm	Ø22 mm	—
High-quality bandpass filter, FWHM=50 nm MBP12-460-50	`MBP12-460-50`	12.5 mm	9 mm	—	View
High-quality bandpass filter, FWHM=10 nm MBP25-1064-10	`MBP25-1064-10`	25 mm	Ø22 mm	—	View
High-quality bandpass filter, FWHM=10 nm MBP12-1064-10	`MBP12-1064-10`	12.5 mm	9 mm	—	View
High-quality bandpass filter, FWHM=10 nm MBP25-1030-10	`MBP25-1030-10`	25 mm	Ø22 mm	—	View
High-quality bandpass filter, FWHM=10 nm MBP12-1030-10	`MBP12-1030-10`	12.5 mm	9 mm	—	View
High-quality bandpass filter, FWHM=10 nm MBP25-780-10	`MBP25-780-10`	25 mm	Ø22 mm	—	View
High-quality bandpass filter, FWHM=10 nm MBP12-785-10	`MBP12-785-10`	12.5 mm	9 mm	—	View
High-quality bandpass filter, FWHM=10 nm MBP25-730-10	`MBP25-730-10`	25 mm	Ø22 mm	—	View
High-quality bandpass filter, FWHM=10 nm MBP12-780-10	`MBP12-780-10`	12.5 mm	9 mm	—	View
High-quality bandpass filter, FWHM=10 nm MBP25-685-10	`MBP25-685-10`	25 mm	22 mm	—	View
High-quality bandpass filter, FWHM=10 nm MBP12-730-10	`MBP12-730-10`	12.5 mm	9 mm	—	View
High-quality bandpass filter, FWHM=10 nm MBP25-660-10	`MBP25-660-10`	25 mm	22 mm	—	View
High-quality bandpass filter, FWHM=10 nm MBP12-685-10	`MBP12-685-10`	12.5 mm	9 mm	—	View
High-quality bandpass filter, FWHM=10 nm MBP25-640-10	`MBP25-640-10`	25 mm	22 mm	—	View
High-quality bandpass filter, FWHM=10 nm MBP12-660-10	`MBP12-660-10`	12.5 mm	9 mm	—	View
High-quality bandpass filter, FWHM=10 nm MBP25-635-10	`MBP25-635-10`	25 mm	22 mm	—	View
High-quality bandpass filter, FWHM=10 nm MBP12-640-10	`MBP12-640-10`	12.5 mm	9 mm	—	View
High-quality bandpass filter, FWHM=10 nm MBP25-594-10	`MBP25-594-10`	25 mm	22 mm	—	View
High-quality bandpass filter, FWHM=10 nm MBP12-635-10	`MBP12-635-10`	12.5 mm	9 mm	—	View
High-quality bandpass filter, FWHM=10 nm MBP25-561-10	`MBP25-561-10`	25 mm	22 mm	—	View
High-quality bandpass filter, FWHM=10 nm MBP12-594-10	`MBP12-594-10`	12.5 mm	9 mm	—	View
High-quality bandpass filter, FWHM=10 nm MBP25-532-10	`MBP25-532-10`	25 mm	22 mm	—	View
High-quality bandpass filter, FWHM=10 nm MBP12-561-10	`MBP12-561-10`	12.5 mm	9 mm	—	View
High-quality bandpass filter, FWHM=10 nm MBP25-488-10	`MBP25-488-10`	25 mm	22 mm	—	View
High-quality bandpass filter, FWHM=10 nm MBP12-532-10	`MBP12-532-10`	12.5 mm	9 mm	—	View
High-quality bandpass filter, FWHM=10 nm MBP25-473-10	`MBP25-473-10`	25 mm	22 mm	—	View
High-quality bandpass filter, FWHM=10 nm MBP12-488-10	`MBP12-488-10`	12.5 mm	9 mm	—	View
High-quality bandpass filter, FWHM=10 nm MBP25-450-10	`MBP25-450-10`	25 mm	22 mm	—	View
High-quality bandpass filter, FWHM=10 nm MBP12-473-10	`MBP12-473-10`	12.5 mm	9 mm	—	View
High-quality bandpass filter, FWHM=10 nm MBP25-405-10	`MBP25-405-10`	25 mm	22 mm	—	View
High-quality bandpass filter, FWHM=10 nm MBP12-450-10	`MBP12-450-10`	12.5 mm	9 mm	—	View
High-quality bandpass filter, FWHM=10 nm MBP25-375-10	`MBP25-375-10`	25 mm	22 mm	—	View
High-quality bandpass filter, FWHM=10 nm MBP25-785-10	`MBP25-785-10`	25 mm	Ø22.0 mm	—	View
High-quality bandpass filter, FWHM=10 nm MBP25-355-10	`MBP25-355-10`	25 mm	9 mm	—	View
High-quality bandpass filter, FWHM=10 nm MBP12-405-10	`MBP12-405-10`	12.5 mm	9 mm	—	View
High-quality bandpass filter, FWHM=10 nm MBP12-375-10	`MBP12-375-10`	12.5 mm	9 mm	—	View
High-quality bandpass filter, FWHM=10 nm MBP12-355-10	`MBP12-355-10`	12.5 mm	9 mm	—	View
