product
WaveQuanta

Reflective Neutral Density Filters, Working Wavelength: 1100 nm-1700 nm, Mounted MNDFR10-04-C

MNDFR10-04-C
$79.01
In Stock
Key Specifications
Wavelength 1100.0nm
Diameter 25.4mm
Request Quote

Design Tools

Wavelength \u2194 Wavenumber Convert between wavelength, frequency, and energy
View all 49 calculators →
RoHS REACH

Reflective Neutral Density Filters, Working Wavelength: 1100 nm-1700 nm, Mounted — Model MNDFR10-04-C

Operating wavelength 1100-1700 mm, ØØ25.4 mm.

Product Description

  • Substrate Material: N-BK7
  • Working Wavelength: 1100-1700 nm
  • OD: 0.2, 0.3, 0.4, 0.5, 1.0, 2.0, 3.0, 4.0
  • Low Power Applications
  • Reflective Neutral Density Filters

LBTEK reflective neutral density filters are made of N-BK7 substrate with chrome-nickel-iron alloy coating, available in optical density (OD) ranges from 0.2 to 4.0. LBTEK filters can be mounted on threaded tubes or coaxial mounting plates for use in coaxial systems, or installed in free space. LBTEK also offers customization services for other special sizes and optical density value attenuators. Please contact Technical Support for any requirements.

Reflective Neutral Density Filters, Working Wavelength: 1100 nm-1700 nm, Mounted

  • Mounted in mechanical housing, removable
  • Optical component size: Ø25.4 mm
  • OD: 0.2, 0.3, 0.4, 0.5, 1.0, 2.0, 3.0, 4.0

LBTEK Round Mounted Reflective Neutral Density Filters have an optical density (OD) range of 0.2-4.0, with an optical component size of Ø25.4 mm. By depositing chrome-nickel-iron alloy (single-sided) on an N-BK7 substrate, a smooth OD value curve is achieved within the 1100-1700 nm range. Although they are reflective neutral density filters, the chrome-nickel-iron alloy coating still absorbs some incident light. To ensure optimal performance, it is recommended that incident light enters from the side with the chrome-nickel-iron alloy coating. At the same time, be careful to prevent contact with this unprotected metal film, as contact may scratch the unprotected surface. It is recommended to use an air blower when cleaning. The MNDFR series of reflective neutral density filters come mountde in detachable standard lens tubes, with their surface engraved with product model, working wavelength, OD value, and other parameters for easy user identification.

Clear Aperture>90%
Operating Wavelength1100-1700 mm
Thickness2 mm
DiameterØ25.4 mm
Specification Sheet PDF — Download
CAD Drawing Download
3D Model (STL) STL — Download
product
WaveQuanta

Raman Dichroic Mirror RT266RDC-UM

RT266RDC-UM
$1,087.21
Request Quote
product
WaveQuanta

Raman Dichroic Mirror RT532RDC-UM

RT532RDC-UM
$1,087.21
Request Quote
product
WaveQuanta

Raman Dichroic Mirror RT785RDC-UM

RT785RDC-UM
$1,087.21
Request Quote
product
WaveQuanta

Raman Dichroic Mirror RT266RDC-R

RT266RDC-R
$1,087.21
Request Quote
product
WaveQuanta

Raman Dichroic Mirror RT355RDC-R

RT355RDC-R
$1,087.21
Request Quote
product
WaveQuanta

Raman Dichroic Mirror RT488RDC-R

RT488RDC-R
$1,087.21
Request Quote
product
WaveQuanta

Raman Dichroic Mirror RT532RDC-R

RT532RDC-R
$1,087.21
Request Quote

Product Family: Reflective Neutral Density Filter, Working Wavelength: 1100 nm-1700 nm (16 variants)

Product ▴▾ SKU Size ▴▾ Clear Aperture ▴▾ Operating Wavelength ▴▾
Reflective Neutral Density Filters, Working Wavelength: 1100 nm-1700 nm, Unmounted NDFR10-4-C NDFR10-4-C Ø25.4 mm >90% 1100-1700 mm View
Reflective Neutral Density Filters, Working Wavelength: 1100 nm-1700 nm, Unmounted NDFR10-3-C NDFR10-3-C Ø25.4 mm >90% 1100-1700 mm View
Reflective Neutral Density Filters, Working Wavelength: 1100 nm-1700 nm, Unmounted NDFR10-2-C NDFR10-2-C Ø25.4 mm >90% 1100-1700 mm View
Reflective Neutral Density Filters, Working Wavelength: 1100 nm-1700 nm, Unmounted NDFR10-1-C NDFR10-1-C Ø25.4 mm >90% 1100-1700 mm View
Reflective Neutral Density Filters, Working Wavelength: 1100 nm-1700 nm, Unmounted NDFR10-05-C NDFR10-05-C Ø25.4 mm >90% 1100-1700 mm View
Reflective Neutral Density Filters, Working Wavelength: 1100 nm-1700 nm, Unmounted NDFR10-04-C NDFR10-04-C Ø25.4 mm >90% 1100-1700 mm View
Reflective Neutral Density Filters, Working Wavelength: 1100 nm-1700 nm, Unmounted NDFR10-03-C NDFR10-03-C Ø25.4 mm >90% 1100-1700 mm View
Reflective Neutral Density Filters, Working Wavelength: 1100 nm-1700 nm, Unmounted NDFR10-02-C NDFR10-02-C Ø25.4 mm >90% 1100-1700 mm View
Reflective Neutral Density Filters, Working Wavelength: 1100 nm-1700 nm, Mounted MNDFR10-4-C MNDFR10-4-C Ø25.4 mm >90% 1100-1700 mm View
Reflective Neutral Density Filters, Working Wavelength: 1100 nm-1700 nm, Mounted MNDFR10-3-C MNDFR10-3-C Ø25.4 mm >90% 1100-1700 mm View
Reflective Neutral Density Filters, Working Wavelength: 1100 nm-1700 nm, Mounted MNDFR10-2-C MNDFR10-2-C Ø25.4 mm >90% 1100-1700 mm View
Reflective Neutral Density Filters, Working Wavelength: 1100 nm-1700 nm, Mounted MNDFR10-1-C MNDFR10-1-C Ø25.4 mm >90% 1100-1700 mm View
Reflective Neutral Density Filters, Working Wavelength: 1100 nm-1700 nm, Mounted MNDFR10-05-C MNDFR10-05-C Ø25.4 mm >90% 1100-1700 mm View
Reflective Neutral Density Filters, Working Wavelength: 1100 nm-1700 nm, Mounted MNDFR10-04-C Current MNDFR10-04-C Ø25.4 mm >90% 1100-1700 mm
Reflective Neutral Density Filters, Working Wavelength: 1100 nm-1700 nm, Mounted MNDFR10-03-C MNDFR10-03-C Ø25.4 mm >90% 1100-1700 mm View
Reflective Neutral Density Filters, Working Wavelength: 1100 nm-1700 nm, Mounted MNDFR10-02-C MNDFR10-02-C Ø25.4 mm >90% 1100-1700 mm View
