MR Photonics
SLD broadband light source
Contact for pricing
Contact Sales
Design Tools
Photonics Calculators
Explore 49 free online calculators for photonics design
Unit Converters
Convert between wavelength, frequency, power, and more
View all 49 calculators →
RoHS
REACH
The SLD (Superluminescent Diode) broadband light source employs a superluminescent semiconductor diode light-emitting chip, which outputs a broadband spectrum with low coherence and simultaneously possesses a high output optical power spectral density. Its operating wavelengths can be selected from bands such as O, S, C, L, and others, making it suitable for applications such as optical OCT (Optical Coherence Tomography) and optical fiber sensing.
Features & Applications
- Ultra-wide spectrum
- Fiber optic sensing
- Low spectral ripple
- Medical lmaging
- Spectral Flatness
- Fiber optic device testing
| Models | Specification |
|---|---|
| Central Wavelength (nm) | 850/1310/1400/1450/1470/1500/1550/1610/1650 |
| Total output power (mW) | 1/5/10 |
| S pectral power d ensity (dBm/nm) | ≥-25 |
| Spectral R ipple (dB) | <0.2 |
| Short-term s tability (15 minutes) (dB) | ≤ ±0.02 |
| Long-term s tability (8 hours) (dB) | ≤ ±0.05 |
| Extinction Ratio PER (dB) | ≤ 0.2 |
| Optical fiber and connectors | Single-model fiber, FC/ APC |
Total output power: Default non-a djustable
Short-term s tability (15 minutes): E quivalent≤± 0.5%
Long-term s tability (8 hours): Equivalent≤± 1.2%
Source: MR Photonics manufacturer datasheet. Download the brochure (PDF) from the Documents tab for full details.
