Biased Photodetectors DETS36-25M

DETS36-25M
$143.82
In Stock
Request Quote

Design Tools

Photonics Calculators Explore 49 free online calculators for photonics design Unit Converters Convert between wavelength, frequency, power, and more
View all 49 calculators →
RoHS REACH

DETS36-25M

Overview

LBTEK biased photodetectors cover Si, InGaAs, and Ge sensor types, offering low noise, fast response, and zero-gain characteristics for a wide range of photodetection applications. With rise times as fast as 1 ns, these detectors directly receive free-space optical input signals.

An internal A23 battery provides the reverse bias voltage. For extended use, an optional DC power supply kit (DET-12V) is available separately.

Key Features

  • Wavelength coverage: 200-2600 nm (model dependent)
  • Free-space optical input
  • Rise time as fast as 1 ns
  • Built-in A23 battery for bias voltage
  • 50 Ω BNC output connector

Applications

  • Optical power monitoring
  • Fiber optic communications testing
  • Laser pulse detection
  • Spectroscopy signal detection
Detector TypeSilicon detector
Input coupling methodFree Space
Detector TypeSilicon detector
Spectral response range350-1100 nm
rise time15 nsab
bandwidth25 MHz
photosensitive size3.6 mm
NEP (Noise Equivalent Power)1.6×10-14 W/Hz1/2
Dark current0.35 nA（Typ.）/6 nA（Max）
Junction capacitance40 pF（Typ.）
Bias voltage10 V
Output voltage~9 V（Hi-Z）;~170 mV（50 Ω）
Operating Temperature10~40 ℃
Storage Temperature-20~70 ℃
Output current0~10 mA
Photosensitive surface depth2.2 mm
Undervoltage indicatorVout≤9 V（Hi-Z）Vout≤170 mA（50 Ω）
weight93±3 g
Lead TimeIn Stock
Specification Sheet PDF — Download
User Manual PDF
Lead Time: 0.0 week0.0s
No CAD drawings available for this product.
