Enhanced Silver Mirror 45°
O-PM-12.7-3.0-BL432$107.14
In Stock
Key Specifications
Wavelength
1425.0nm
Diameter
12.7mm
Design Tools
Time-Bandwidth Product
Check if your pulse is transform-limited
Pulse Stretching & Compression
Calculate GVD, TOD, and pulse broadening
Gaussian Beam Calculator
Model beam propagation through your optical system
Sellmeier Equation
Look up refractive index by wavelength
View all 49 calculators →
Complete Your Setup
RoHS
REACH
Overview
Enhanced silver mirror for optimized broadband visible–NIR applications. Multi-layer dielectric stack over silver for enhanced reflectance >99%.
Applications
- High-throughput broadband beam routing
- High-finesse cavity and resonator optics
- Sensitive imaging and detection systems
- Low-loss broadband signal routing
Construction & Performance
- Substrate: HPFS 7980 0F
- Coating: Metallic Coating (R>99.5%@350-2500nm)
- Wavelength range: 350.0–2500.0 nm
- Angle of incidence: 45°
- Diameter: 12.7 mm (+0/-0.1mm)
- Thickness: 3.0 mm (+0/-0.1mm)
Storage & Handling
Store in clean, dry environment at 20–25°C and 40–60% relative humidity. Handle with lint-free gloves and avoid mechanical contact with optical surfaces. Clean using optical-grade solvents and lens tissue when necessary.
| Center Wavelength | 1425.0 nm |
| Wavelength Range | 350.0 – 2500.0 nm |
| Angle of Incidence | 45° |
| Diameter | 12.7 mm (+0/-0.1mm) |
| Thickness | 3.0 mm (+0/-0.1mm) |
| Substrate | HPFS 7980 0F |
| Coating Type | Metallic Coating |
| Coating Specification | R>99.5%@350-2500nm |
No documents available for this product.
No CAD drawings available for this product.
Product Family: Femtosecond Flat Mirrors (47 variants)
| Product | SKU | Diameter | Thickness | Wavelength Range | |
|---|---|---|---|---|---|
| Enhanced Silver Mirror 45° |
O-PM-25.4-6.0-BL439
| 25.4 mm | 6.0 mm | 700.0–1050.0 nm | View |
| Enhanced Silver Mirror 45° |
O-PM-25.4-3.0-BL440
| 25.4 mm | 3.0 mm | 350.0–2500.0 nm | View |
| Protected Silver Mirror |
O-PM-25.0-6.35-BL056
| 25.4 mm | 6.35 mm | 600.0–2000.0 nm | View |
| Enhanced Silver Mirror 45° Current |
O-PM-12.7-3.0-BL432
| 12.7 mm | 3.0 mm | 350.0–2500.0 nm | |
| Protected Silver Mirror 0-45° |
O-PM-12.7-4.0-BL431
| 12.7 mm | 4.0 mm | 350.0–2500.0 nm | View |
| Protected Silver Mirror 45° |
O-PM-12.7-6.0-BL430
| 12.7 mm | 6.0 mm | 350.0–2500.0 nm | View |
| Protected Silver Mirror D-Shape 0-45° |
O-PM-12.7-6.0-BL429
| 12.7 mm | 6.0 mm | 350.0–2500.0 nm | View |
| Enhanced Silver Mirror 0-45° |
O-PM-12.7-6.35-BL428
| 12.7 mm | 6.35 mm | 600.0–1000.0 nm | View |
| Protected Silver Mirror 0-45° |
O-PM-12.7-6.35-BL427
| 12.7 mm | 6.35 mm | 350.0–2500.0 nm | View |
| Protected Silver Mirror |
O-PM-25.0-6.0-BL057
| 25.0 mm | 6.0 mm | 400.0–2000.0 nm | View |
| Low-dispersion ultraviolet mirror 351nm 0° |
O-PM-25.4-BL050
| 25.4 mm | — | 351.0–351.0 nm | View |
| Low-dispersion ultraviolet mirror 351nm 0° |
O-PM-50.8-BL049
| 50.8 mm | — | 351.0–351.0 nm | View |
| Low-Dispersion Ultraviolet Mirror D-Shape 266nm 45.5° |
O-PM-25.4-9.0-BL048
| 25.4 mm | 9.0 mm | 266.0–266.0 nm | View |
| Low-dispersion ultraviolet mirror 266nm 45.5° |
O-PM-50.8-9.0-BL047
| 50.8 mm | 9.0 mm | 266.0–266.0 nm | View |
| Low-dispersion ultraviolet mirror 266nm 45.5° |
O-PM-25.4-9.0-BL046
| 25.4 mm | 9.0 mm | 266.0–266.0 nm | View |
| Low-Dispersion 800nm Mirror 45° |
O-PM-25.4-6.0-BL438
| 25.4 mm | 6.0 mm | 750.0–850.0 nm | View |
| Low-Dispersion 800nm Mirror 45° |
O-PM-50.8-9.0-BL040
| 50.8 mm | 9.0 mm | 740.0–860.0 nm | View |
| Low-Dispersion 800nm Mirror 45° |
O-PM-38.1-9.0-BL039
| 38.1 mm | 9.0 mm | 740.0–860.0 nm | View |
| Low-Dispersion 800nm Mirror 45° |
O-PM-25.4-9.0-BL038
| 25.4 mm | 9.0 mm | 740.0–860.0 nm | View |
| Low-Dispersion 800nm Mirror 45° |
O-PM-25.4-8.0-BL037
| 25.4 mm | 8.0 mm | 740.0–860.0 nm | View |
| Low-Dispersion Broadband Mirror 45° |
O-PM-25.4-6.0-BL437
| 25.4 mm | 6.0 mm | 750.0–1100.0 nm | View |
| Low-Dispersion Broadband Mirror 45° |
O-PM-7.0-2.0-BL055
| 7.0 mm | 2.0 mm | 750.0–1100.0 nm | View |
| Low-Dispersion Broadband Mirror 45° |
O-PM-25.4-6.0-BL442
| 25.4 mm | 6.0 mm | 1350.0–2060.0 nm | View |
| Low-Dispersion Broadband Mirror 45° |
O-PM-25.4-6.0-BL441
| 25.4 mm | 6.0 mm | 1180.0–1600.0 nm | View |
| Low-Dispersion 1550nm Mirror 45° |
O-PM-25.4-5.0-BL054
| 25.4 mm | 5.0 mm | 1570.0–1630.0 nm | View |
| Low-Dispersion 1550nm Mirror 45° |
O-PM-12.7-3.0-BL053
| 12.7 mm | 3.0 mm | 1525.0–1575.0 nm | View |
| Low-Dispersion 1550nm Mirror 45° |
O-PM-50.8-12.7-BL052
| 50.8 mm | 12.7 mm | 1510.0–1630.0 nm | View |
| Low-Dispersion Dual-Wavelength Mirror 0° |
O-PM-25.4-6.35-BL484
| 25.4 mm | 6.35 mm | 1030515.0–1030515.0 nm | View |
| Low-Dispersion Dual-Wavelength Mirror 45° |
O-PM-25.4-3.0-BL483
| 25.4 mm | 3.0 mm | 1030515.0–1030515.0 nm | View |
| Low-Dispersion 1030nm Mirror 45° |
O-PM-50.8-9.0-BL482
| 50.8 mm | 9.0 mm | 1010.0–1050.0 nm | View |
| Low-Dispersion 1030nm Mirror 0° |
O-PM-25.4-6.0-BL481
| 25.4 mm | 6.0 mm | 950.0–1100.0 nm | View |
| Low-Dispersion 1030nm Mirror 30° |
O-PM-25.4-6.0-BL435
| 25.4 mm | 6.0 mm | 1010.0–1070.0 nm | View |
| Low-Dispersion 1030nm Mirror 45° |
O-PM-12.7-6.0-BL434
| 12.7 mm | 6.0 mm | 1010.0–1050.0 nm | View |
| Low-Dispersion 1030nm Mirror 30° |
O-PM-12.7-6.0-BL433
| 12.7 mm | 6.0 mm | 1010.0–1070.0 nm | View |
| Low-Dispersion 1030nm Mirror 45° |
O-PM-38.1-9.0-BL035
| 38.1 mm | 9.0 mm | 1030.0–1030.0 nm | View |
| Low-Dispersion 1030nm Mirror 0° |
O-PM-25.4-6.0-BL033
| 25.4 mm | 6.0 mm | 1030.0–1030.0 nm | View |
| Low-Dispersion 1030nm Mirror 45° |
O-PM-50.8-9.0-BL030
| 50.8 mm | 9.0 mm | 1010.0–1050.0 nm | View |
| Low-Dispersion 1030nm Mirror 0° |
O-PM-25.4-6.0-BL029
| 25.4 mm | 6.0 mm | 1010.0–1050.0 nm | View |
| Low-Dispersion 1030nm Mirror 45° |
O-PM-12.7-6.35-BL028
| 12.7 mm | 6.0 mm | 1010.0–1050.0 nm | View |
| Low-Dispersion 1030nm Mirror 0° |
O-PM-12.7-6.0-BL027
| 50.8 mm | 9.0 mm | 1010.0–1050.0 nm | View |
| Low-Dispersion 1030nm Mirror 45° |
O-PM-50.8-9.0-BL026
| 25.4 mm | 6.0 mm | 950.0–1100.0 nm | View |
| Low-Dispersion 1030nm Mirror 0° |
O-PM-25.4-6.0-BL024
| 12.7 mm | 6.0 mm | 950.0–1100.0 nm | View |
| Low-Dispersion 1030nm Mirror 0° |
O-PM-12.7-6.0-BL023
| 25.4 mm | 9.0 mm | 950.0–1100.0 nm | View |
| Low-Dispersion 1030nm Mirror 45° |
O-PM-25.4-9.0-BL022
| 25.4 mm | 9.0 mm | 515.0–515.0 nm | View |
| Low-Dispersion 1030nm Mirror 45° |
O-PM-25.4-6.0-BL021
| 25.4 mm | 6.0 mm | 515.0–515.0 nm | View |
| Low-Dispersion 1030nm Mirror 0° |
O-PM-25.4-6.0-BL020
| 25.4 mm | 6.0 mm | 515.0–515.0 nm | View |
| Low-Dispersion 1030nm Mirror 45° |
O-PM-12.7-6.35-BL019
| 12.7 mm | 6.35 mm | 515.0–515.0 nm | View |
