Protected Silver Mirror 0-45°
O-PM-12.7-4.0-BL431$107.14
In Stock
Key Specifications
Wavelength
1425.0nm
Diameter
12.7mm
Design Tools
Time-Bandwidth Product
Check if your pulse is transform-limited
Pulse Stretching & Compression
Calculate GVD, TOD, and pulse broadening
Gaussian Beam Calculator
Model beam propagation through your optical system
Sellmeier Equation
Look up refractive index by wavelength
View all 49 calculators →
Complete Your Setup
RoHS
REACH
Overview
Protected silver mirror for broadband visible–NIR (350–2500 nm) applications. High broadband reflectance with dielectric overcoat for tarnish protection.
Applications
- General laser beam routing across visible–NIR
- Broadband interferometry and imaging
- Spectroscopy across wide wavelength ranges
- Reflective telescope and beam expander optics
Construction & Performance
- Substrate: UVFS
- Coating: Metallic Coating (R>99.5%@350-2500nm)
- Wavelength range: 350.0–2500.0 nm
- Angle of incidence: 0 - 45°
- Diameter: 12.7 mm (+0/-0.1mm)
- Thickness: 4.0 mm (+0/-0.1mm)
Storage & Handling
Store in clean, dry environment at 20–25°C and 40–60% relative humidity. Handle with lint-free gloves and avoid mechanical contact with optical surfaces. Clean using optical-grade solvents and lens tissue when necessary.
| Center Wavelength | 1425.0 nm |
| Wavelength Range | 350.0 – 2500.0 nm |
| Angle of Incidence | 0 - 45° |
| Diameter | 12.7 mm (+0/-0.1mm) |
| Thickness | 4.0 mm (+0/-0.1mm) |
| Substrate | UVFS |
| Surface Flatness | λ/10@633nm |
| Surface Quality | S1: 20-10 |
| Coating Type | Metallic Coating |
| Coating Specification | R>99.5%@350-2500nm |
No documents available for this product.
No CAD drawings available for this product.
