Fixed Aspheric Fiber Collimator AFC780-4-APC

AFC780-4-APC
$347.72
In Stock
Key Specifications
Wavelength 780.0nm
Request Quote

Design Tools

Wavelength \u2194 Wavenumber Convert between wavelength, frequency, and energy
View all 49 calculators →

Complete Your Setup

Lasers & Sources Detectors & Measurement Optomechanics Lenses
RoHS REACH

The fixed aspheric fiber collimators provided by LBTEK have no moving parts, featuring a compact structure unaffected by misalignment, which simplifies free-space laser-to-fiber coupling. LBTEK offers customized collimator services, including connector types, housing dimensions, output beam size, and other specifications. For specific customization requirements, please contact LBTEK Technical Support.

  • Collimated spot diameter: 2.0~3.6 mm
  • Mechanical housing diameter: 11 mm
  • FC/APC connector
Specifications diagram
Operating Wavelength 780 nm
Output spot diameter 4 mm
Anti-reflection coating range 600-1050 nm
Material D-ZK3
Focal length 18.40 mm@780 nm
Thread specification M11
Connector Type FC/APC
Housing Material Non-magnetic stainless steel
Housing Diameter 11.0 mm
Divergence angle ≤0.021°
AR Coating Reflectance Ravg<0.5%@600-1050 nm
NA<sub>lens</sub> 0.15
No documents available for this product.
No CAD drawings available for this product.
