FTIRzz
High-resolution FTIR spectrometer for ultrafast laser characterization
Overview
FTIRzz is a compact, high-resolution Fourier Transform InfraRed spectrometer designed specifically for ultrafast laser pulse characterization in the mid-infrared range. It provides real-time spectral analysis from 1.6 to 12 µm with 2.5 cm⁻¹ spectral resolution.
Key Features
- Broadband MIR spectral coverage: 1.6–12 µm
- High spectral resolution: 2.5 cm⁻¹
- Compatible with 1 kHz to multi-MHz and CW sources
- Minimum pulse energy: 10 nJ
- Compact footprint
Applications
- MIR ultrafast laser characterization
- OPA/OPCPA output spectrum monitoring
- Nonlinear spectroscopy
| Spectral Resolution | 2.5 cm⁻¹ |
| Spectral Range | 1.6–12 µm |
| Spectral Range (cm⁻¹) | 833–6250 cm⁻¹ |
| Spectral Resolution (cm⁻¹) | Down to 2.5 cm⁻¹ |
| Laser Repetition Rate Range | 1 kHz to multi-MHz and CW |
| Minimum Pulse Energy | 10 nJ |
| Trigger Input | High level TTL |
| Input Beam Requirements | Free space, 5 mm diameter |
| Polarization Requirement | Any polarization |
| PC Requirements | Windows 10, 1 USB3 port |
