Glan-Taylor Crystal Polarizing Prism GTP10-IR
GTP10-IR$1,579.30
In Stock
Key Specifications
Wavelength
700.0nm
Design Tools
SHG Phase Matching
Calculate phase matching angles and efficiency
Wavelength \u2194 Wavenumber
Convert between wavelength, frequency, and energy
View all 49 calculators →
Complete Your Setup
RoHS
REACH
Glan-Taylor Crystal Polarizing Prism — Model GTP10-IR
Glan-Taylor polarizing prism, Laser-grade α-BBO, operating wavelength 700 nm-3.0 μm, clear aperture Ø10 mm, extinction ratio 10000:1.
Overview
LBTEK Glan-Taylor Crystal Polarizing Prisms feature a high damage threshold air-spaced structure with laser-grade Calcite or α-BBO substrates. Operating wavelength covers 200 nm-3.0 μm (segmented), with extinction ratio up to >100000:1. Available with optional AR coatings at 245 nm, 532 nm, 1064 nm. Side absorber improves polarization purity. Housed in a standard rotation mount.
Key Features
- Extinction ratio: 10000:1
- Operating wavelength: 700 nm-3.0 μm
- Material: Laser-grade α-BBO
- Structure: High damage threshold air-spaced structure
- Beam deviation: <3 arcmin
- Optional AR coating: P coating@1064 nm
Applications
- Laser polarization control and beam separation
- High-power laser systems requiring stable extinction ratio
- Polarimetry and ellipsometry
- Optical isolation and Faraday rotator combinations
- Imaging and spectroscopy with polarization discrimination
| Optical component material | Laser-grade α-BBO |
| Structural design | High damage threshold air-spaced structure |
| Clear Aperture | Ø10 mm |
| Beam Deviation | <3 arcmin |
| Transmitted Wavefront Error (premium) | λ/4 (emergent/incident surface), Ø8.5 mm |
| Operating Wavelength | 700 nm-3.0 μm |
| Extinction ratio | 10000:1 |
| Optional AR coating | P coating@1064 nm |
| Field of view | >4° REF |
| Housing Diameter | Ø25.4 mm |
| Length | 16 mm |
| Surface finish (scratches/pits) | 20/10 (emergent/incident surface) |
| Housing thread | SM1 external thread |
| Transmitted Wavefront Error (TWE) | λ/4, Ø8.5 mm |
Click and drag to rotate. Scroll to zoom.
Product Family: Glan-Taylor Crystal Polarizing Prism (7 variants)
| Product | SKU | Size | Clear Aperture | Operating Wavelength | |
|---|---|---|---|---|---|
| Glan-Taylor Crystal Polarizing Prism GTP10-IR Current |
GTP10-IR
| Ø25.4 mm | Ø10 mm | 700 nm-3.0 μm | |
| Glan-Taylor Crystal Polarizing Prism GTP10-A |
GTP10-A
| Ø25.4 mm | Ø10 mm | 300 - 700 nm | View |
| Glan-Taylor Crystal Polarizing Prism GTP10-UV |
GTP10-UV
| Ø25.4 mm | Ø10 mm | 200 nm-300 nm | View |
| Glan-Taylor Crystal Polarizing Prism GTP10 |
GTP10
| Ø25.4 mm | Ø10 mm | 350 nm-2.3 μm | View |
| Glan-Taylor Crystal Polarizing Prism GTP05-A |
GTP05-A
| Ø12.7 mm | Ø5 mm | 300 nm-700 nm | View |
| Glan-Taylor Crystal Polarizing Prism GTP05-UV |
GTP05-UV
| Ø12.7 mm | Ø5 mm | 220 nm-300 nm | View |
| Glan-Taylor Crystal Polarizing Prism GTP05 |
GTP05
| Ø12.7 mm | Ø5 mm | 350 nm-2.3 μm | View |
