Quartz Zero-Order Quarter-Wave Plate — QWP50-1064B-SP
QWP50-1064B-SP$1,322.27
In Stock
Key Specifications
Transmittance
0.5%
Design Tools
Photonics Calculators
Explore 49 free online calculators for photonics design
Unit Converters
Convert between wavelength, frequency, power, and more
View all 49 calculators →
Complete Your Setup
RoHS
REACH
Quartz Zero-Order Quarter-Wave Plate — Model QWP50-1064B-SP
λ/4 quartz waveplate at design wavelength, mounted in standard SM housing.
Overview
LBTek's Quartz Zero-Order Quarter-Wave Plates deliver a λ/4 retardance at the design wavelength. The air-spaced compound design combines two quartz plates for cost-effective zero-order performance. Each plate is anti-reflection coated on both surfaces (R < 0.25% @ design wavelength) and mounted in a standard SM05 or SM1 lens tube for seamless integration into polarization control setups.
Key Features
- Zero-Order (air-spaced compound) design at the specified design wavelength
- Retardance: λ/4
- V-type anti-reflection coating on both surfaces
- Surface finish 10/5 to 20/10
- Operating temperature tolerant, polarization-stable
- Mounted in standard SM05 / SM1 housing for seamless integration
Applications
- Polarization state conversion (linear ↔ circular / elliptical)
- Laser isolator, interferometry, and ellipsometry systems
- Quantum optics and photonic research
- Integration with polarizing beamsplitters and prisms
| Optical component material | Quartz Crystal |
| Diameter | 50.0 mm |
| Diameter tolerance | +0.0/-0.1 mm |
| Clear Aperture | Ø45.0 mm |
| Thickness | <2.8 mm |
| Design Wavelength | 1064 nm |
| Anti-reflective coating | R<0.5%ᵃ@Design Wavelength (0°incidence angle, single surface) |
| Latency | λ/4 |
| Delay accuracy | ±λ/300 |
| Surface finish (scratches/pits) | 60/40 |
| Transmitted Wavefront Error (TWE) (@633 nm) | λ/8 |
| Surface Parallelism | <10 arcsec |
No CAD drawings available for this product.
