WaveQuanta

Electro-Optic Phase Modulator (EOM) EOPM-BB-C

EOPM-BB-C
$6,611.32
In Stock· Ships in 3.0 weeks
Key Specifications
Wavelength 1000.0nm
Transmittance 0.2%
Request Quote

Design Tools

Time-Bandwidth Product Check if your pulse is transform-limited Pulse Stretching & Compression Calculate GVD, TOD, and pulse broadening Wavelength \u2194 Wavenumber Convert between wavelength, frequency, and energy
View all 49 calculators →

Complete Your Setup

Lasers & Sources Mirrors Nonlinear Crystals Optomechanics
RoHS REACH

Broadband Free-Space Phase Modulator

This LBTEK broadband electro-optic phase modulator (EOM) provides wide-bandwidth (DC to 100 MHz) optical phase modulation via the linear electro-optic effect in lithium niobate. The wider bandwidth enables high-frequency sideband generation and fast laser control.

Optimized for ultrafast laser and quantum optics applications requiring rapid phase modulation. Multiple wavelength bands (UV/VIS/NIR) are available with custom AR coating options.

Key Features

  • DC to 100 MHz modulation bandwidth (broadband)
  • Lithium niobate electro-optic crystal
  • Compatible with high-speed RF drivers and waveform generators
  • AR-coated for the operating wavelength
  • Low residual amplitude modulation (RAM)

Typical Applications

  • Pulsed laser shaping (sub-MHz to 100 MHz)
  • High-frequency PDH locking
  • Quantum information processing — qubit control sidebands
  • Coherent optical communication
  • Atomic clock laser stabilization
  • Frequency-modulated spectroscopy (FMS)

Product Family

The EOPM-BB series broadband phase modulators provide DC-to-100 MHz bandwidth for fast laser phase control. Available in multiple wavelength bands. Custom Vπ and bandwidth on request.

SKU: EOPM-BB-C · Sourced from LBTEK · Distributed by WaveQuanta

Operating Wavelength 1000-1650 nm
Modulation Bandwidth DC-100 MHz
Electro-Optic Crystal Material Lithium Niobate
Operating Wavelength 258V@1064nm
Electro-Optic Crystal Material ≥98%±1%
Optical Damage Threshold 2 W
Clear Aperture 3 mm
User Manual PDF
Lead Time: 3.0 week1s
CAD Drawing Download
3D Model (STL) STL — Download
