SM1.5 Lens Tube SM1.5-50A
SM1.5-50A$36.45
In Stock
Design Tools
View all 49 calculators →Complete Your Setup
RoHS
REACH
SM1.5 Lens Tube — Model SM1.5-50A
✔ In Stock — Ships Today
The LBTEK internal and external threaded lens sleeve features SM1.5 external threads on one end and SM1.5 internal threads on the other, primarily designed for securing Ø38.1 mm optical components. It adopts an expandable design, making it suitable for quickly assembling compact optical systems. Each lens sleeve comes with an SM1.5R retaining ring for securing optical components.
Key Features
- One end with SM1.5 external thread, the other end with SM1.5 internal thread
- Expandable design for building multi-component optical systems
- Includes 1 SM1.5R retaining ring
- Optional sleeve lengths: 8 mm, 12.5 mm, 25 mm, and 50 mm
Application
One end with SM1.5 external thread, the other end with SM1.5 internal thread
| Clear Aperture | 34.8 mm |
CAD Drawing
Download
Click and drag to rotate. Scroll to zoom.
Product Family: SM1.5 Lens Tube (4 variants)
| Product | SKU | Size | Clear Aperture | Operating Wavelength | |
|---|---|---|---|---|---|
| SM1.5 Lens Tube SM1.5-8A |
SM1.5-8A
| — | — | — | View |
| SM1.5 Lens Tube SM1.5-12.5A |
SM1.5-12.5A
| — | — | — | View |
| SM1.5 Lens Tube SM1.5-25A |
SM1.5-25A
| — | — | — | View |
| SM1.5 Lens Tube SM1.5-50A Current |
SM1.5-50A
| — | — | — |
