What wavelength range does Ultra-fast Mirrors UFPM20-B2-SP support?

Ultra-fast Mirrors UFPM20-B2-SP operates at a center wavelength of 970.0 nm.

What are the physical dimensions of Ultra-fast Mirrors UFPM20-B2-SP?

Ultra-fast Mirrors UFPM20-B2-SP dimensions: Diameter: 50.8 mm. Thickness: 12.0 mm.

Is Ultra-fast Mirrors UFPM20-B2-SP available for purchase?

Yes, request a quote for pricing and lead time at WaveQuanta.Contact our sales team for current availability and volume pricing.

WaveQuanta

Ultra-fast Mirrors UFPM20-B2-SP

Name: Ultra-fast Mirrors UFPM20-B2-SP
Brand: WaveQuanta
SKU: UFPM20-B2-SP
Price: 549.64 SGD
Availability: InStock

UFPM20-B2-SP

$549.64

In Stock

Key Specifications

Wavelength 970.0nm

Diameter 50.8mm

Reflectance 99.0%

Request Quote

Design Tools

Time-Bandwidth Product Check if your pulse is transform-limited Pulse Stretching & Compression Calculate GVD, TOD, and pulse broadening Gaussian Beam Calculator Model beam propagation through your optical system Wavelength \u2194 Wavenumber Convert between wavelength, frequency, and energy

View all 49 calculators →

RoHS REACH

Ultra-fast Mirrors UFPM20-B2-SP

Reflectance Rs＞99%@970-1150 nm, Rp＞99%@1020-1080 nm（45°AOI）, Ø50.8 mm.

Overview

LBTek Ultrafast Mirrors are dispersion-controlled HR optics for sub-100 fs pulses. Low-GDD broadband HR coatings preserve transform-limited pulses across Ti:Sapphire, Yb-doped, and OPA wavelengths.

Key Features

Reflectance: Rs＞99%@970-1150 nm, Rp＞99%@1020-1080 nm（45°AOI）
Diameter: 50.8 mm
Thickness: 12 mm
Clear Aperture: ＞90%CA
Surface Quality: 20/10
Surface Flatness: λ/10 @633 nm
Parallelism: ＜10 arcsec

Applications

Femtosecond Ti:Sapphire systems
Yb-doped fiber/disk amplifiers
OPA/NOPA cavities
Pulse compression chains
Pump-probe spectroscopy

Center Wavelength	970.0 nm
Reflectance	99.0%
Diameter	50.8 mm
Thickness	12.0 mm
Clear Aperture	90.0 mm

No documents available for this product.

No CAD drawings available for this product.

Product Family: Ultra-fast Mirrors (13 variants)

Product ▴▾	SKU	Size ▴▾	Clear Aperture ▴▾	Operating Wavelength ▴▾
Ultra-fast Steering Mirrors UFPM10-A2	`UFPM10-A2`	25.4 mm	>90%CA	460 nm-590 nm	View
Ultra-fast Steering Mirrors UFPM10-B1	`UFPM10-B1`	25.4 mm	>90%CA	710 nm-900 nm	View
Ultra-fast Steering Mirrors UFPM10-B2	`UFPM10-B2`	25.4 mm	>90%CA	970 nm-1150 nm	View
Ultra-fast Steering Mirrors UFPM10-C	`UFPM10-C`	25.4 mm	>90%CA	1400 nm-1700 nm	View
Ultra-fast Steering Mirrors UFPM05-A2	`UFPM05-A2`	12.7 mm	>90%CA	460 nm-590 nm	View
Ultra-fast Steering Mirrors UFPM05-B1	`UFPM05-B1`	12.7 mm	>90%CA	710 nm-900 nm	View
Ultra-fast Steering Mirrors UFPM05-B2	`UFPM05-B2`	12.7 mm	>90%CA	970 nm-1150 nm	View
Ultra-fast Steering Mirrors UFPM20-B1	`UFPM20-B1`	50.8 mm	>90%CA	710 nm-900 nm	View
Ultra-fast Steering Mirrors UFPM20-A2	`UFPM20-A2`	50.8 mm	>90%CA	460 nm-590 nm	View
Ultra-fast Steering Mirrors UFPM20-B2	`UFPM20-B2`	50.8 mm	>90%CA	970 nm-1150 nm	View
Ultra-fast Steering Mirrors UFPM20-C	`UFPM20-C`	50.8 mm	>85%CA	1400 nm-1700 nm	View
Ultra-fast Steering Mirrors UFPM05-C	`UFPM05-C`	12.7 mm	>85%CA	1400 nm-1700 nm	View
Ultra-fast Mirrors UFPM20-B2-SP Current	`UFPM20-B2-SP`	—	—	—
