30 mm coaxial mounting plate — Model OPM-9RA
✔ In Stock — Ships Today
LBTEK 30 mm Round Coaxial Mounting Plate, 9 mm Thickness, with SM1 Threaded Through Hole, Suitable for Mounting 25.4 mm Diameter Optical Components. External dimensions come in two types: SM2 Thread and 50.8 mm Diameter Smooth Bore, which can be mounted to SM2 Internal Threaded Mechanical Components or 50.8 mm Diameter Smooth Bore Internal Hole Mechanical Components. The 4 coaxial rod through holes are compatible with 30 mm coaxial systems, and each side has 1 locking screw that can be tightened with a 1.5 mm hex wrench.
Key Features
- Material: 6061-T6 Aluminum Alloy
- SM1 Through Internal Thread
- Thickness 9 mm
Application
30 mm round coaxial panel mounted on a 2-inch lens holder
| Clear Aperture | 23.5 mm |
CAD Drawing
Download
Click and drag to rotate. Scroll to zoom.
Product Family: 30 mm coaxial mounting plate (11 variants)
