High-power white LED LBHLED-6500K
LBHLED-6500K$993.63
In Stock
Design Tools
Photonics Calculators
Explore 49 free online calculators for photonics design
Unit Converters
Convert between wavelength, frequency, power, and more
View all 49 calculators →
Complete Your Setup
RoHS
REACH
LBTEK's high-power white LED consists of collimating optics, a copper heat sink, a silent fan, and a mechanical housing. This design composition enables an output beam divergence angle of less than 7°, stable output power, and minimal overheating damage. It offers four color temperature options: 4000K, 5000K, 5700K, and 6500K. The mechanical housing features 4×M4 threaded holes on the sides and 4×M3 threaded holes on the front. The light exit port has an SM1 internal thread, allowing connection with other standard SM1 threaded devices. When paired with the LBLED-CT7V controller, light intensity can be adjusted directly via the knob on the controller, and it also supports external triggering and software control.
Note: The light source controller needs to be purchased separately.
Key Features
- Four color temperatures available
- Maximum optical power reaches 3.4W
- Divergence angle: <7°
- Supports external trigger and software control
Application
High-power white LED installation method
| Color temperature | 6500K |
| Maximum Optical Power | 3.4 W |
| Divergence angle | ＜7° |
| Output Aperture | 25 mm<sup>a</sup> |
| Recommended Driver | LBLED-CT7V |
| Forward Current | 4.8 A (maximum not exceeding 5 A) |
| Forward Voltage | 7 V (not exceeding 7 V) |
| Lifetime | >10000 h |
| Operating Temperature | 10~30 ℃ |
| Operating Temperature | 0~40 ℃ |
| Size | 60 mm×60 mm×92 mm |
| Weight | 670 g |
