Mitutoyo Plan Apochromat Dry Objectives, 355 nm-532 nm MPLNAPO100XNUV

Name: Mitutoyo Plan Apochromat Dry Objectives, 355 nm-532 nm MPLNAPO100XNUV
Brand: LBTek
SKU: MPLNAPO100XNUV
Availability: InStock

MPLNAPO100XNUV

Contact for pricing

In Stock

Contact Sales

Design Tools

Gaussian Beam Calculator Model beam propagation through your optical system

View all 49 calculators →

Complete Your Setup

Lasers & Sources Mirrors Lenses Detectors & Measurement

RoHS REACH

LBTEK offers Mitutoyo plan apochromat dry objectives with an operating wavelength range of 355 nm to 532 nm and magnifications of 20X, 50X, and 100X. Each objective is effectively focused across its operating wavelength range and features external 26 mm × 0.706 mm threads. Using the LBTEK SM1-M26A thread adapter, these lenses can be mounted on internally SM1-threaded mounts. All three plan apochromat dry objectives are suitable for brightfield microscopy. Specific specifications are listed in the product specification sheet.

Key Features

Long working distance
Infinity-corrected plan semi-apochromatic design
Designed for use with 200mm focal length tube lenses
Thread specification: W26 mm×0.706 mm
Working wavelength: 355 nm-532 nm

Application

The objective is mounted to an optical component using the SM1-M26A thread adapter.

No specifications available for this product.

No documents available for this product.

No CAD drawings available for this product.
