Olympus Plan Achromat Dry Objectives OPLN4X
OPLN4X$144.08
In Stock
Design Tools
View all 49 calculators →Complete Your Setup
RoHS
REACH
LBTEK offers Olympus Plan Achromat Dry Objectives with magnifications of 4X, 10X, 20X, and 40X. Each objective features standard RMS threading and can be mounted to SM1 internal threaded mounts using LBTEK's SM1-RMSA threaded adapter. All four of these objectives are suitable for bright-field microscopy, while the 10X, 20X, and 40X magnification models are also compatible with dark-field microscopy. For detailed specifications, please refer to the product specification list.
Key Features
- Infinity-corrected plan achromatic design
- Designed for use with tube lenses of 180 mm focal length
- Thread type: W20.32 mm×0.706 mm (RMS)
Application
Using a threaded adapter SM1-RMSA to mount the objective lens onto the optical component mount.
| Magnification | 4X |
| Numerical Aperture | 0.10 |
| Tube Length | N/A |
| Working distance | 18.5 mm |
| Objective Field Number | 22 mm |
| Parfocal distance | 45 mm |
| Immersion liquid | Air/Dry |
| Focal length | 45 mm |
| Incident aperture | 9 mm |
| Operating Wavelength | 400 nm-700 nm |
| Optical Correction | Infinity Corrected |
| Field of View | W20.32 mm×0.706 mm (RMS) |
No documents available for this product.
No CAD drawings available for this product.
