Orion-1030-200 Femtosecond Laser - 200W @ 100kHz
Contact for pricing
In Stock
Contact Sales
Design Tools
Time-Bandwidth Product
Check if your pulse is transform-limited
Pulse Stretching & Compression
Calculate GVD, TOD, and pulse broadening
View all 49 calculators →
Complete Your Setup
RoHS
REACH
The high-power Orion models deliver 120 W to 300 W with pulse energy up to 2 mJ and pulse durations below 400 fs. TEM00 with M² ≤ 1.3, Burst mode 1-10 pulses, water-cooled 980 × 560 × 153 mm chassis.
This page covers the Orion-1030-200 configuration. Specifications below are for this model only; sibling models in the Orion series are listed as separate products.
Specifications transcribed from the Yi-Laser product page (2026-08-27). Contact WaveQuanta for a quotation, lead time and customisation options.
Other models in the Orion series
- Orion-1030-80 — the next step down in average power (80 W)
- Orion-1030-300 — the next step up in average power (300 W)
- Orion-343-30 — the same platform at 343 nm (30 W)
- Orion-515-120 — the same platform at 515 nm (120 W)
Browse the full femtosecond laser range, or see the complete ultrafast laser line.
| Central Wavelength | 1030 ± 5nm |
| Output Power | 200W @ 100kHz |
| Repetition Rate | 1Hz - 2MHz |
| Pulse Energy | 2mJ |
| Power Stability | < 1.0%(8 hours, RMS) |
| Pulse Duration | < 400fs |
| Beam Quality | TEM00, M²≤1.3 |
| Beam Roundness | > 90% |
| Beam Diameter | 3.0 ± 0.5mm |
| Burst Pulse Number | 1 - 10 |
| Dimensions | 980 x 560 x 153mm |
| Trigger Mode | PSO / POD / Gate mode, and TTL trigger |
| External Power Control | 0 - 5V, linear control |
| Warm-up Time | ≤ 15 min |
| Power Supply | AC100 - 240V / 50 - 60Hz |
| Operating Humidity | < 60% RH @ 25℃ |
| Operating Temperature | 22 - 30℃ |
| Cooling Method | Water circulation cooling |
