Orion-343-5-ND Femtosecond Laser - 5W @ 1000kHz
Contact for pricing
In Stock
Contact Sales
Design Tools
Time-Bandwidth Product
Check if your pulse is transform-limited
Pulse Stretching & Compression
Calculate GVD, TOD, and pulse broadening
View all 49 calculators →
Complete Your Setup
RoHS
REACH
The Orion series ultrafast femtosecond lasers cover 1030 nm, 515 nm and 343 nm with a 1 Hz - 2 MHz repetition rate range. Users can trade low-repetition high-energy against high-repetition medium-energy operation to suit the process.
This page covers the Orion-343-5-ND configuration. Specifications below are for this model only; sibling models in the Orion series are listed as separate products.
Specifications transcribed from the Yi-Laser product page (2026-08-27). Contact WaveQuanta for a quotation, lead time and customisation options.
Other models in the Orion series
- Orion-343-30 — the next step up in average power (30 W)
- Orion-515-10-ND — the same platform at 515 nm (10 W)
- Orion-1030-20-ND — the same platform at 1030 nm (20 W)
Browse the full femtosecond laser range, or see the complete ultrafast laser line.
| Central Wavelength | 343 ± 3nm |
| Output Power | 5W @ 1000kHz |
| Repetition Rate | 1Hz - 2MHz |
| Pulse Energy | 5μJ |
| Power Stability | < 1.0%(8 hours, RMS) |
| Pulse Duration | < 400fs |
| Beam Quality | TEM00, M²≤1.2 |
| Beam Roundness | > 90% |
| Beam Diameter | 2.0 ± 0.5mm |
| Burst Pulse Number | 1 |
| Dimensions | 660 x 337 x 150.5mm |
| Trigger Mode | PSO / POD / Gate mode, and TTL trigger |
| External Power Control | 0 - 5V, linear control |
| Warm-up Time | ≤ 15 min |
| Power Supply | AC100 - 240V / 50 - 60Hz |
| Operating Humidity | < 60% RH @ 25℃ |
| Operating Temperature | 22 - 30℃ |
| Cooling Method | Water circulation cooling |
