Post Holder Set — Model KPH-40-B

✔ In Stock — Ships Today

The post holder set (B) comprises a standard post holder, a magnetic mount for standard post holder, a fork-type clamp and posts in seven lengths. The magnetic mount for standard post holder is secured through the M6 waist-type mounting holes on the fork-type clamp. The magnetic mount provides clamping force for alignment adjustment before fixation on optical tables. To meet diverse customer needs, LBTEK offers both individual sets and 10-set packages for all seven variants. For example, the KPH-30-B-P10 set contains four components: the OP-30 post, the PH-30A post holder, the PR-1S magnetic mount for standard post holder and the PHC-32S fork-type clamp.

Key Features

The set includes a standard post holder, a magnetic mount for standard post holder, a fork-type clamp and posts;
Assortment of seven post holder lengths;
The set includes 12.7 mm diameter posts with an M4 screw at the top;
Individual sets or 10-set bundles are available;

Application

Installation effect diagram.

No specifications available for this product.

No documents available for this product.

No CAD drawings available for this product.
