Post Holder Set — Model KPH-40-G-P10

✔ In Stock — Ships Today

The post holder set (G) comprises an integrated magnetic mount for post holders and posts in seven lengths. Featuring a magnetic 360° rotary clamp at its base with M6 mounting holes, the mount ensures the secure attachment of the post holder to optical tables or breadboards. The magnetic mount provides pretensioning force before being secured to the optical tables, facilitating alignment adjustment. To meet diverse customer needs, LBTEK offers both individual sets and 10-set packages for all seven variants. For example, the KPH-150-G-P10 set contains two components: the OP-150 post and the LPH-150 magnetic mount for integrated post holder.

Key Features

The set includes an magnetic mount for integrated post holder and posts;
Assortment of seven post holder lengths;
The set includes 12.7 mm diameter posts with an M4 screw at the top;
Individual sets or 10-set bundles are available;

Application

Installation effect diagram.

No specifications available for this product.

No documents available for this product.

No CAD drawings available for this product.
