SM2 Lens Tube — Model SM2-6A
✔ In Stock — Ships Today
The LBTEK internal and external threaded lens sleeve features SM2 external threads on one end and SM2 internal threads on the other, primarily used for securing optical components with a diameter of Ø50.8 mm. It adopts a stackable design, making it suitable for quickly assembling compact optical systems. Each lens sleeve comes with an SM2R retaining ring for fixing the optical components.
Key Features
- SM2 external threads at one end, SM2 internal threads at the opposite end
- Expandable design for building multi-component optical systems
- Includes 1 SM2R retaining ring
- Lens tube lengths available: 6 mm, 8 mm, and 25 mm
Application
SM2 external threads at one end, SM2 internal threads at the opposite end
| Size | 6 mm |
| Clear Aperture | Ø48.3 mm |
| Material | 6061-T6 Aluminum Alloy |
| Surface Treatment | Black anodized |
| Applicable optical element diameter | Ø50.8 mm |
| Maximum applicable thickness of optical components | 3.5 mm |
| Compatibility | SM2 |
| Rod mounting threaded hole | SM2R/1 piece |
CAD Drawing
Download
Click and drag to rotate. Scroll to zoom.
