Stainless Steel Precision Adjusting Thread Pair M4X02-S14
M4X02-S14$29.08
In Stock
Design Tools
Photonics Calculators
Explore 49 free online calculators for photonics design
Unit Converters
Convert between wavelength, frequency, power, and more
View all 49 calculators →
RoHS
REACH
The Stainless Steel Precision Adjusting Thread Pair M4X02-S14 from WaveQuanta is a high-performance Stages Actuators designed for micrometer-precision optical alignment and positioning. Available from stock for immediate shipment. Sourced directly from WaveQuanta, this product meets the high standards required for scientific research and precision photonics applications.
✔ In Stock — Ships Today
LBTEK stainless steel precision adjustment thread pair, M4×0.2 is mainly used in opto-mechanical motion products, such as common optical mount series products, to control the precision of product movement. The diameter of the stainless steel hex adjuster is M4, with a 2mm internal hex hole in the head. The recommended aperture size for the stainless steel thread bushing is Ø 5.5mm (0~+0.02mm). The combination of the two achieves an adjustment precision of 0.2mm/revolution.
Key Features
- Adjustment accuracy: 0.2mm/revolution
- Recommended bore size for threaded bushing: 5.5mm (0~+0.02mm)
- Maximum adjustment range: 3.5mm
Application
Side placement of M4×0.2 stainless steel precision adjustment thread pair
| Lead Time | In Stock |
No CAD drawings available for this product.
