Z-axis Translation Stage Assembly Kit LS75-50-XZ
LS75-50-XZ$132.31
In Stock
Design Tools
Photonics Calculators
Explore 49 free online calculators for photonics design
Unit Converters
Convert between wavelength, frequency, power, and more
View all 49 calculators →
Complete Your Setup
RoHS
REACH
LBTEK offers two assembly kits, each containing a mounting plate and a vertical bracket for vertically mounting two LS75-50-series single-axis translation stages relative to each other. The LS75-50-XZ assembly kit can construct an XZ translation stage from two single-axis stages, while the LS75-50-YZ assembly kit can construct a YZ translation stage from two single-axis stages. Both kits can also be combined with a base plate and a single-axis stage to form a Z-axis translation stage. Each assembly kit includes a mounting plate with M6 tapped holes arranged in the same pattern as the tapped hole array on the stage surface. The mounting plate features two M4 countersunk holes for mounting optomechanics. Note: Optomechanics must first be secured with M4 socket head screws before fixing the mounting plate to the translation stage.
Key Features
- The kit includes angle brackets and Z-axis mounting plates;
- Support for X-axis, Z-axis, XZ-axis, YZ-axis, or XYZ-axis configurations;
- Compatible with LS75-50 series translation stages；
Application
Use LS75-50-XZ to construct the XZ translation stage and use LS75-50-YZ to construct the YZ translation stage.
No specifications available for this product.
No documents available for this product.
No CAD drawings available for this product.
