Precilasers
1.5 µm Low Phase Noise Femtosecond Laser
Contact for pricing
Contact Sales
Design Tools
Time-Bandwidth Product
Check if your pulse is transform-limited
Pulse Stretching & Compression
Calculate GVD, TOD, and pulse broadening
View all 49 calculators →
RoHS
REACH
1.5 µm Narrow-Spectrum Femtosecond Laser Femtosecond laser -->
Features
- Broad Spectrum High Power
- Linear Polarization Customizable Wavelength
- High Power Stability
Applications
- Atomic and Molecular Photophysics
- Precision Measurement Ultrafast Imaging
| Models | Specification |
|---|---|
| Customizable Wavelength Range | 1530-1590 nm |
| Pulse Width | Compressible to <100 fs |
| Pulse Energy | 0.5-1 nJ |
| Average Power | 6-200 mW |
| Maximum peak power | >20 kW |
| Spectral Width | >15 nm |
| Repetition Frequency | 50-250 MHz |
| Timing Jitter (Free-running) | <10fs[1kHz-10MHz@10G] |
| Operating mode | Pulsed |
| Operating temperature (without condensation) | 15-35 °C |
| Power supply | 100V-240V, AC, 50/60Hz |
| Communication | RS422 |
| Chassis dimension | 483mm×526mm×130mm |
Source: Precilasers manufacturer datasheet. Download the brochure (PDF) from the Documents tab for full details.
No CAD drawings available for this product.
Product Family: Femtosecond Lasers (7 variants)
| Product | SKU | Size | Clear Aperture | Operating Wavelength | |
|---|---|---|---|---|---|
| 780nm Femtosecond laser |
| — | — | — | Contact |
| 1560-1590nm Femtosecond laser |
| — | — | — | Contact |
| 1.5 µm Narrow-Spectrum Femtosecond Laser |
| — | — | — | Contact |
| 1.5 µm Low Phase Noise Femtosecond Laser Current |
| — | — | — | |
| 1800-2130nm Broadband tunable femtosecond laser |
| — | — | — | Contact |
| 1530-1590nm Femtosecond laser |
| — | — | — | Contact |
| 1030-1110nm Femtosecond laser |
| — | — | — | Contact |
