16 mm coaxial adjustable aperture CSD8-05
CSD8-05Design Tools
Complete Your Setup
The 16 mm coaxial adjustable aperture CSD8-05 from WaveQuanta is a high-performance Mounts Holders designed for precision optical alignment and component mounting. Available from stock for immediate shipment. Sourced directly from WaveQuanta, this product meets the high standards required for scientific research and precision photonics applications.
✔ In Stock — Ships Today
The LBTEK 16 mm coaxial adjustable aperture is driven by a lever and compatible with 16 mm coaxial systems, allowing smooth and continuous opening and closing of the aperture. The iris aperture is housed in an ultra-thin aluminum casing with an overall thickness of 5.7 mm. It can be secured to the coaxial rod using a 2.0 mm hex key by tightening the side M4 set screw. The aperture diameter is continuously adjustable from Ø0.8 mm to Ø8.0 mm. The blades are driven by a round-headed lever, which is offset from the fourth coaxial post for convenient adjustment within the coaxial system.
Key Features
- Integrated structure aperture stop for 16 mm coaxial systems
- Aperture diameter continuously adjustable from Ø0.8 mm to Ø8.0 mm
- With thickness of 5.7 mm
Application
For 16 mm coaxial systems
| Lead Time | In Stock |
