Triaxial Fiber Collimator FP-19.5

The LBTEK Three-Axis Fiber Collimator Adapter Accessories can be used to achieve various connections for three-axis fiber collimators, meeting the installation requirements of three-axis fiber collimators in different application scenarios. The TAD-19.5 features SM1 external threads, enabling the connection of three-axis fiber collimators to optical component mounts with SM1 internal threads. The FP-19.5 is equipped with three M3 threaded holes on the side for securing fiber collimators, and three M4 countersunk holes on the bottom for compatibility with various fiber coupler bases. The TF-19.5 includes four M2 countersunk holes, facilitating the connection between three-axis fiber collimators and various five-axis fiber coupler accessories. The SL-19.5 features an M18.6×0.5 internal thread, allowing the connection of three-axis fiber collimators to semiconductor lasers. All four adapter accessories come with a Ø19.5 mm inner bore and M3 threaded holes, enabling the use of a 1.5 mm hex wrench to adjust M3 set screws for securing three-axis fiber collimators. LBTEK offers customized services for special surface treatments and thread specifications. For inquiries, please contact technical support.

• Ø19.5 mm inner bore for installing a three-axis fiber collimator
• Fixed with set screws
• 4 adapter options available
