Ø12.7 mm Post Collar — Model OPRM-2
✔ In Stock — Ships Today
The Ø12.7 mm post alignment collar assembly from LBTEK maintains post height and rotational orientation. It comprises two components: a post holder collar fixed to the post holder, and an OPRM-3 post collar. For optimal performance, tighten the thumb screw of the post holder against the post holder collar. The screw is positioned as correspondingly shown(see right diagram). When adjusting the rotational position of the post holder collar, the thumb screw on the holder should carry sufficient load to ensure dual-line contact between the post and the post holder. Both the post holder collar and post collar are secured using M4 screws.
Key Features
- 6061-T6 aluminum alloy
- Height fixation and rotational orientation capability for Ø12.7 mm posts;
- Steel ball and V-groove design enabling repeatable positioning (angle <0.5°);
Application
OPRM-2 is used to maintain height and rotational orientation
No specifications available for this product.
CAD Drawing
Download
Click and drag to rotate. Scroll to zoom.
