Ø12.7 mm Post Collar — Model OPRM-4
✔ In Stock — Ships Today
When optical components and their mounts require a flat surface during translation or rotation, the OPRM-4 contact block functions as an intermediate interface. The contact block supports posts to maintain height. It features five contact pads on the top, bottom, and sides for simple, flexible use. Mounted on the outside diameter of a Ø12.7 mm post, the OPRM-4 is secured with a side-mounted M4 rubber-tipped screw.
Key Features
- Intermediate interface for moving components
- Five wear-resistant contact pads for component positioning
- Lockable slide-on collar design for Ø12.7 mm posts connection;
Application
The OPRM-4 contact block is used in conjunction with the OPRM-6 adjustable fixed stop and can serve as a rotary stop.
No specifications available for this product.
CAD Drawing
Download
Click and drag to rotate. Scroll to zoom.
