Precision pinhole PS05-35H

PS05-35H
$155.51
In Stock· Ships in 8.0 weeks
Request Quote

Design Tools

Photonics Calculators Explore 49 free online calculators for photonics design Unit Converters Convert between wavelength, frequency, power, and more
View all 49 calculators →

Complete Your Setup

Lasers & Sources Mirrors Lenses Detectors & Measurement
RoHS REACH

Precision pinhole PS05-35H

✔ In Stock — Ships Today

LBTEK offers stainless steel precision pinholes with selectable pinhole diameters ranging from Ø5 to Ø1000 µm. The stainless steel pinhole plates are uncoated and are housed in an aluminum alloy casing with an outer diameter of Ø12.7 mm, allowing for convenient installation into Ø12.7 mm mounting brackets. The manufacturing process of the stainless steel pinholes may leave slight marks on the metal plate, which are normal processing residues and do not affect functionality. Note: The pinhole metal plate is relatively thin, and some products may exhibit minor deformation around the edges of the metal plate. However, this does not affect the functionality or use of the pinhole.

Key Features

  • Shell material 6061-T6 aluminum alloy
  • Pinhole metal sheet material is 300 series stainless steel
  • Standard pinhole without coating treatment

Application

The precision pinhole is often installed in an adjustment mount with SM05 internal threads.

Lead Time8.0 weeks
Specification Sheet PDF — Download
Lead Time: 8.0 week1s
CAD Drawing Download
3D Model (STL) STL — Download
