2nd Order Distributed Fiber Raman Amplifier
Contact for pricing
Contact Sales
Design Tools
Photonics Calculators
Explore 49 free online calculators for photonics design
Unit Converters
Convert between wavelength, frequency, power, and more
View all 49 calculators →
RoHS
REACH
On the basis of the first-order fiber Raman amplifier, the second-order fiber Raman amplifier incorporates a pump laser in the 1340~1360nm wavelength band to provide Raman gain for the 14xx nm laser of the first-order Raman amplifier. This effectively reduces system noise and is suitable for amplifying optical signals in longer-distance unrepeated optical transmission systems. The second-order fiber Raman amplifier must be used in conjunction with the first-order fiber Raman amplifier.
Features & Applications
- Wide operating wavelength
- High Gain
- Low noise figure
- Applications
- Long-distance fiber communication
- Fiber optic distributed sensing
- Fiber Laser
| Models | Specification |
|---|---|
| Pump W avelength (nm) | 1340~1360 |
| Signal Wavelength | 1425~1465 |
| Raman Gain (dB) | 10/20 |
| Gain Flatness (dB) | <2 |
| Pump P ower (mW) | 300/500/1000/1400 |
| Degree of p olarization (DOP) of p ump l ight | 5% (Typ ical )，10%(Max) |
| Polarization d ependent gain (dB) | <0.2 |
| Polarization m ode d ispersion (ps) | <0.5 |
| Input/ O utput Isolation (dB) | >35 |
| Noise Figure (dB) | 0 |
| Optical Fiber | SMF-28 |
| Fiber connectors | FC/APC |
| Control Mode | AP P C（Automatic p ump power c ontrol） |
Signal Wavelength: Customizable
Pump P ower: Customizable
Source: MR Photonics manufacturer datasheet. Download the brochure (PDF) from the Documents tab for full details.
