Mianna-Pico OEM picosecond laser: 450ps pulses, 0.7GW peak power and dual-pulse mode for fast, accurate tattoo and pigmentation removal. Compatible with Beamtech picosecond accessories and matched power supplies.
The Mianna-Pico series picosecond laser is a standout laser in our aesthetic picosecond laser family, offering high cost-performance and a compact size as its main advantages. The picosecond mode of Mianna-Pico provides 450ps laser pulses with peak power up to 0.7GW, making it an excellent device for pigment removal and scar treatment.
Like other picosecond lasers from Beamtech, the Mianna-Pico series can be equipped with all Beamtech picosecond accessories, such as the picosecond articulated arm, picosecond handpiece, zoom handpiece, and fractional handpiece.
The Mianna-Pico laser head features an independent seed driver circuit design, making it compatible with existing nanosecond Q-switched power supplies.
Key Features
- Cost-effective, comparable to the price of nanosecond Q-switched lasers
- Peak power 0.7GW, 450ps pulse width
- Picosecond dual-pulse (pulse-to-pulse) mode
- Uniform flat-top beam distribution
- Compatible power supply with nanosecond Q-switched lasers
- Provide with matched power supply, articulated arm, zoom handpiece, and MLA/DOE handpiece.
| Models | Mianna-Pico |
|---|---|
| Wavelength | 1064nm/ 532nm |
| Pulse width | ~450ps@1064nm&532nm |
| Repetition Rate | 1~10Hz |
| Pulse Energy @ 1064nm (Single pulse mode) | 400mJ |
| Pulse Energy @ 532nm (Single pulse mode) | 200mJ |
| Pulse Energy @ 1064nm (Double pulse mode) | 700mJ |
| Pulse Energy @ 532nm (Double pulse mode) | 300mJ |
| Pulse Energy Range @ 1064nm | 100 ~ 400mJ |
| Pulse Energy Range @ 532nm | 50 ~200mJ |
| Beam Profile | Flat- Top |
| Beam Size | 10mm |
| Operating Temperature | 20°C ~ 25°C(Environment Temperature) |
| Beam Divergence | ~1 mrad |
| Dimension | 200 x 530 x 143 mm³ (W x L x H) |
Source: Beamtech manufacturer datasheet. Download the brochure (PDF) from the Documents tab for full details.
