Precision Optical Mount AMM3-05BS

LBTEK Type B Precision Optical Mount, smooth bores, no knobs, uses set screws to secure optical components. The bottom of the mount is equipped with M4 tapped holes or countersunk holes for M4 screws to connect with optical posts. Type B precision optical mounts all use rubber-tipped screws to secure optical components, with minimum applicable optical component thicknesses of 2.0 mm, 3.0 mm, and 4 mm respectively. The AMM3-11BS, AMM3-05B, and AMM3-05BS models each come with 3 M5X025-22KLB precision adjustment threaded pairs, while the AMM3-1B, AMM3-1.5B, and AMM3-2B models each come with 3 M6X025-22KLB precision adjustment threaded pairs. All threaded bushings feature a flexure clamp mechanism with clamping screws that can be secured using a 2.0 mm hex key. The AMM3-11BS and AMM3-05BS models without knobs are suitable for compact space. Purchasing LBTEK precision optical mounts includes one free 2.0 mm hex key, with the 1-inch, 1.5-inch, and 2-inch series additionally including 2 M4 socket head cap screws.
