Fixed Pellicle Mounts — Model FMS-TF

✔ In Stock — Ships Today

The LBTEK Fixed Pellicle Mount has overall dimensions of 32 mm × 21.5 mm × 10 mm, capable of mounting 25.4 mm diameter thin film polarizers with a thickness range of 3.0 mm to 5.5 mm, featuring a clear aperture of 23.0 mm. The mount base includes an M4 countersunk hole for posts and other optical components. Purchasing LBTEK's Fixed Pellicle Mount includes one M4×6 hex socket head cap screw and a wrench.

Key Features

  • Dimensions 32 mm × 21.5 mm × 10 mm
  • For thin film polarizer thickness range: 3.0 mm - 5.5 mm
  • Embedded mounting method

Application

FMS-TF with Thin Film Polarizer

Material 6061-T6 aluminum alloy
Surface Treatment Black anodized
Size 32 mm×21.5 mm×10 mm
Clear Aperture Ø23.0 mm
Applicable optical element diameter Ø25.4 mm
Center Hole Diameter 3.0 mm-5.5 mm
Attribute 188 M4 countersunk hole
Hex Key Wrenches Included 1 M4×6 hex socket head cap screw and wrench
Specification Sheet PDF — Download
CAD Drawing Download
3D Model (STL) STL — Download
