Ultra-Low Phase Noise Rep-Rate Locked Femtosecond Comb Er-FrComb-1560-ULN
Contact for pricing
In Stock
Contact Sales
Design Tools
Photonics Calculators
Explore 49 free online calculators for photonics design
Unit Converters
Convert between wavelength, frequency, power, and more
View all 49 calculators →
RoHS
REACH
Repetition rate locked with sub-50 fs timing jitter. Supplied by WaveQuanta as LuminHao model Er-FrComb-1560-ULN.
Key features
- One-button automatic locking, no operator intervention
- Repetition rate built to a specified value
- Repetition rate tracks the reference source automatically
- High stability under normal laboratory conditions
Applications
- Terahertz metrology
- Time and frequency transfer
- Femtosecond ranging
- High-precision metrology
Specifications transcribed from the manufacturer product page. Contact WaveQuanta for a quotation, lead time and customisation options.
Related comb hardware
- HM-Fceo detection module — add this to close the f_ceo loop and make the comb fully locked
- Er-Comb-1560-U fully locked comb — the already fully locked version, if you do not want to build the loop
- HNFA1000 amplifier module — boosts pulse energy before nonlinear broadening
Browse the full optical frequency comb range.
| Repetition rate (20-500 MHz customisable) | 200 MHz |
| Repetition-rate tuning range | 10 kHz |
| Central wavelength | 1560 nm +/- 10 nm |
| Spectral width | > 20 nm |
| In-loop rep-rate lock instability | < 5E-14 @ 1 s (RF reference) |
| Pulse timing jitter, 10 Hz - 1 MHz | < 50 fs |
| Average power | 100 mW |
| Pulse duration | < 100 fs |
| Operating temperature | 10 to 35 degC |
| Steady-state power consumption | < 35 W |
| Weight | < 5 kg |
| Dimensions | 270 x 200 x 70 mm |
