Princeton Instruments
PIXIS-XO Soft X-ray CCD Camera
PI-PIXIS-XO-2048Contact for pricing
In Stock
Contact Sales
Design Tools
View all 49 calculators →Complete Your Setup
RoHS
REACH
The PIXIS-XO is a vacuum-compatible, thermoelectrically cooled CCD camera for direct soft X-ray and EUV detection. The back-thinned sensor in a permanent vacuum housing provides high quantum efficiency across the soft X-ray spectrum without the need for phosphor coatings. TE cooling to -70°C eliminates cryogen logistics in beamline environments.
Key Features
- Direct soft X-ray detection (no phosphor)
- Permanent vacuum enclosure
- Back-thinned CCD sensor
- Thermoelectric cooling to -70°C
- No cryogens required
- Multiple sensor formats
- Beamline-compatible design
Applications
- Synchrotron soft X-ray imaging
- EUV characterization
- X-ray absorption spectroscopy
- Plasma diagnostics
Specifications
| Parameter | Value |
|---|---|
| Wavelength Range Min | 0.06 nm |
| Wavelength Range Max | 124.0 nm |
| Sensor Type | Back-Thinned CCD (Vacuum, TE) |
| Pixel Size | 13.5 µm |
| Resolution | 2048x2048 px |
| Frame Rate | 2.0 fps |
| Cooling Method | Thermoelectric (Vacuum) |
| Cooling Temperature | -70.0 °C |
| Spectral Range | 10eV-20keV nm |
| Quantum Efficiency | 80.0 % |
| Dark Current | 0.001 e⁻/px/s |
| Weight | 5.0 kg |
| Wavelength Range | 0.06 – 124.0 nm |
| Dark Current | 0.001 e/px/h |
| Quantum Efficiency | 80.0% |
| Weight | 5.0 kg |
| Sensor Type | Back-Thinned CCD (Vacuum, TE) |
| Pixel Size | 13.5 μm |
| Resolution | 2048x2048 |
| Frame Rate | 2.0 fps |
| Cooling Method | Thermoelectric (Vacuum) |
| Cooling Temperature | -70.0 °C |
| Spectral Range | 10eV-20keV |
