Optical Frequency Comb Tooth Extraction System OFCTES
Contact for pricing
In Stock
Contact Sales
Design Tools
Photonics Calculators
Explore 49 free online calculators for photonics design
Unit Converters
Convert between wavelength, frequency, power, and more
View all 49 calculators →
RoHS
REACH
Locks and extracts a single comb tooth as a CW reference. Supplied by WaveQuanta as LuminHao model OFCTES.
Key features
- Integrated module design
- Fast channel switching
- High stability
- Robust in operation
Applications
- Electromagnetic spectrum sensing
- Comb-tooth amplification
Specifications transcribed from the manufacturer product page. Contact WaveQuanta for a quotation, lead time and customisation options.
Related comb hardware
- Er-Comb-1560-U fully locked comb — the fully locked comb this system extracts a tooth from
- HM-Fbeat detection module — the beat detection used to lock onto the selected tooth
- Er-FrComb-1560-GHz comb — GHz spacing makes individual teeth easier to isolate
Browse the full optical frequency comb range.
| Operating wavelength | Target wavelength +/- 1 nm |
| Side-mode suppression ratio | > 20 dB |
| Automatic locking | Yes |
| Input comb repetition rate | 1 to 6 GHz |
| Switchable locked-tooth channels | 5 @ 3 GHz |
| Input optical power | 0 dBm |
| Fibre connector | FC/APC |
No documents available for this product.
No CAD drawings available for this product.
