Phasics
Kaleo MultiWAVE Interferometer
PHA-KALEO-MWContact for pricing
In Stock
Contact Sales
Design Tools
Time-Bandwidth Product
Check if your pulse is transform-limited
Pulse Stretching & Compression
Calculate GVD, TOD, and pulse broadening
View all 49 calculators →
Complete Your Setup
RoHS
REACH
The Phasics Kaleo MultiWAVE is a multi-wavelength, large dynamic range interferometer for testing coated and uncoated optics at their working wavelengths. Supporting up to 8 wavelengths from 193 nm to 14 µm, it offers measurement accuracy comparable to Fizeau interferometry while being insensitive to vibrations.
Key Features
- Up to 8 wavelengths (193 nm to 14 µm)
- High dynamic range (500 fringes)
- WFE and MTF measurement
- Insensitive to vibration
- Compatible with MetroPro and ISO standards
Applications
- Coated optics and filters testing at operating wavelengths
- High dynamics surface testing
- Space and defense optics qualification
- Automotive optics testing
| Wavelength Range | 193 nm to 14 µm (custom wavelengths available) |
| Absolute Accuracy | 80 nm PV |
| Configuration | Double pass |
| Measurement Capability | RWE of reflective surfaces, TWE of transparent optics |
| Number of Wavelengths | 1 or 2 (standard), up to 8 (custom) |
| Clear Aperture | 5.1 inches (130 mm) |
| Beam Height | 108 mm |
| Alignment FOV | ±2° |
| Pupil Focus Range | ±2.5 m |
| RMS Repeatability | <0.7 nm (<λ/900) |
| Dynamic Range (Defocus) | 500 fringes (SFE=150 µm) |
| Sample Reflectivity Range | ~4% - 100% |
| Vibration Isolation | Not necessary |
| Dimensions (W×H×L) | 910 x 600 x 260 mm³ |
| Weight | 25 kg |
| Key Features | Up to 8 wavelengths, High dynamic range, WFE & MTF measurement, Insensitive to vibration, Compatible with MetroPro & ISO |
